Kirin 985 5G Officially Debuts – Supports 5G With Better Signal Coverage!

Last updated:

Today, on April 15, Kirin 985 5G officially enters as the third 5G SoC in the Kirin family after Kirin 990 5G and Kirin 820 5G.

Kirin 985 highlights

Kirin 985 5G Specification Sheet

SoC Kirin 985
Release Date April 15, 2020
Process 7nm TSMC FinFET+
CPU 1 x Cortex A76 (2.58 GHz), 3 x Cortex A76 (2.4 GHz), 4 x Cortex A55 (1.84GHz)
GPU Mali-G77 MP8 (8 cores) Frequency???
AI Dual-core Da-Vinci NPU
Connectivity Integrated 5G modem, Download 1277 Mbps and the upload rate is 173 Mbps
ISP ISP 5.0
First Phone Honor 30 (standard version)

Kirin 985 5G – A Faster, Better, 5G supported Kirin 980?

Starting with the process, Kirin 985 features the TSMC’s 7nm LPP FinFET+ process. Similar to the Kirin 820, it’s N7P, DUV-based. In terms of CPU configuration, Kirin 985 5G has a tri-cluster design with the octa-core design (1+3+4). The high-performance core is  Cortex A76 core running at a speed of 2.58 GHz. There are three Cortex A76 cores at a speed of 2.4GHz clock speed acting as mid-performance clusters. Last but not least, we have four power-efficient Cortex A55 cores at a speed of 1.84GHz for less demanding tasks.

Kirin 985 5G highlights 4

SoC Kirin 980 Kirin 985 Kirin 990 Kirin 990 5G
High-Performance Cores 2 x Cortex A76 (2.6 GHz) 1 x Cortex A76 (2.58 GHz) 2 x Cortex A76 (2.86 GHz) 2 x Cortex A76 (2.86 GHz)
Mid-Performance Cores 2 x Cortex A76 (1.92 GHz) 3 x Cortex A76 (2.4 GHz) 2 x Cortex A76 (2.09 GHz) 2 x Cortex A76 (2.09 GHz)
Low-Performance Cores 4 x Cortex A55 (1.80GHz) 4 x Cortex A55 (1.84GHz) 4 x Cortex A55 (1.86GHz) 4 x Cortex A55 (1.86GHz)
Process 7nm FF+ TSMC 7nm FF+ EUV 7nm FF+ TSMC 7nm FF+EUV

GPU & AI

Considering the graphical performance, we have an eight-core Mali-G77 GPU MP8. There’s the dual-core NPU (2 big cores) of the famous DaVinci architecture categorizing it in the top 4 of AI-benchmark. ISP 5.0 is the same as the Kirin 990’s ISP.

Kirin 985 5G highlights 3

SoC Kirin 980 Kirin 985 Kirin 990 Kirin 990 5G
GPU Mali-G76 GPU MP10 Mali-G77 GPU MP8 Mali-G76 GPU MP16 Mali-G76 GPU MP16
Cores 10 8 16 16
Frequency 720 MHz ??? 600 MHz 700 MHz

Kirin 985 highlights 5G Speed

Connectivity

Kirin 985 highlights its integrated single-chip 5G baseband solution without a plug-in. It supports 2G / 3G / 4G / 5G network standard and NSA / SA 5G dual-mode. The theoretical maximum download rate is 1277 Mbps and the upload rate is 173 Mbps. Compared to the combination of Snapdragon 865 + Snapdragon X55 it is about 40% and 75% faster, respectively.

Kirin 985 5G networked compared with X55 SD 865 1

It is specially optimized for high-speed scenarios. For example, at a speed of 90 km/hour, the download rate and upload rate can still reach 589 Mbps and 63 Mbps, respectively, which is 31% and 37% faster than the combination of Snapdragon 865 and Snapdragon X55.

Kirin 985 5G networked compared with X55 SD 865

Since the capacity isn’t that much, the energy efficiency of Kirin 985 5G appears to be high. According to the officials, the power consumption under 5G heavy load and light load scenarios are only 504 mA and 291 mA, respectively, and the energy efficiency ratio is about 1.5 times that of Snapdragon 865 + Snapdragon X55.

Kirin 985 5G highlights 2

Other features include 5G anti-jamming capability, 5G low latency, 5G energy efficiency, and 5G high-speed scene performance.

The first phone to feature Kirin 985 is the Honor 30 Standard Variant.
