Anker Soundcore P20i Manual | Pairing & Charging Guide

The Anker Soundcore P20i earbuds come with specs such as a 10mm dynamic driver and built-in microphones in each earbud, Game mode support while using the Soundcore app, up to 10 hours of battery life on a single charge, Bluetooth 5.3 technology and a working connection range of 10 meters of 33 feet, SBC audio support, and much more. Learn how to use these earbuds using this Anker Soundcore P20i manual!

If you are interested in purchasing these earbuds, you can easily do it using the Amazon online store. Also, in case you are interested in giving the original manual a look, you can do it here.

Anker Soundcore P20i Specs Sheet

Model	Anker Soundcore P20i
Weight	Earbuds and charging case: Around 45 grams
Waterproof/IP ratings	IPX5
Bluetooth version	V5.3
Range/Distance	10 meters
Connectivity Port/Charging Cable	Type-C
Audio Decoding	SBC
Driver	10mm
Speaker frequency response	20Hz – 20kHz
Battery Life	Earbuds: Around 10 hours Charging case: Around 20 hours
Charging Time	Earbuds: Around 2 hours Charging case: Around 2 hours
App Support	Yes, Soundcore App
Controls/Features	Play and pause a song, play the next and previous song, answer, end, and reject a call, activate the voice assistant
Accessories	Charging case, USB cable, user manual, ear tips
Price	Around 25 USD

Anker Soundcore P20i Accessories

The earbuds come with the following accessories:

• Charging case.
• USB cable.
• User manual.
• Ear tips.

Anker Soundcore P20i Manual | Guide & Troubleshooting

How To Pair The Earbuds? – Mono Mode

Step 1: Pair both earbuds with the device.

Step 2: When in dual mode, place one of the earbuds into the charging case. The other one will continue working by itself.

How To Control These Earbuds? – Mono Mode

• Play or pause a song: Press the touch control area on the selected earbud two times.
• Answer an incoming call: Press the touch control area on the selected earbud two times.
• End a current call: Press the touch control area on the selected earbud two times.
• Reject an incoming call: Press and hold the touch control area on the selected earbud for about 2 seconds.

How To Reset And Re-Pair The Earbuds?

Step 1: Delete the soundcore P20i earbuds from the devices’ Bluetooth list.

Step 2: Take the earbuds out of the case.

Step 3: Within one minute of the earbuds powering on, press and hold the touch control area on both earbuds for about 10 seconds, or until you hear a notification sound.

This will reset the earbuds.

Step 4: Search for a new device.

Step 5: Select the soundcore P20i earbuds. If a password is needed, type “0000” or “1234”.

After that, the pairing will be done.

How To Charge The Earbuds?

Earbuds

To charge the earbuds, all you have to do is place them into the charging case and close its lid. The earbuds will start charging automatically.

Charging Case

To charge the charging case, all you have to do is connect the case to a USB charger or charging port. It will start charging automatically.

What Do The Lights Mean?

Charging Case

• A green light flashing while charging: The case is charging.
• A green light on while charging: The case is fully charged.
• A white light flashing with the earbuds inside: The earbuds are charging.
• A white light on with the earbuds inside: The earbuds are fully charged.

How To Wear These Earbuds?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

How To Turn On And Off?

Turn On

Automatically: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically.

Turn Off

Automatically: Place the earbuds into the charging case and close its lid. After that, the earbuds will turn off automatically.

How To Pair The Earbuds? – Dual Mode

To Android And iOS Devices

Step 1: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically and pair with each other.

The earbuds will now be ready to pair with any device.

NOTE: If the earbuds don’t enter pairing mode automatically, then press and hold the touch control area on both earbuds for about 3 seconds.

Step 2: Unlock the desired device.

Step 3: Go to the device’s settings.

Step 4: Turn on Bluetooth on the desired device.

Step 5: Search for a new device.

Step 6: Select the soundcore P20i earbuds. If a password is needed, type “0000” or “1234”.

After that, the pairing will be done.

To Windows (PC)

Step 1: Turn on the Window’s Bluetooth.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Click on Bluetooth.

Step 6: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically and pair with each other.

The earbuds will now be ready to pair with any device.

NOTE: If the earbuds don’t enter pairing mode automatically, then press and hold the touch control area on both earbuds for about 3 seconds.

Step 7: Select the soundcore P20i earbuds. If a password is needed, type “0000” or “1234”.

After that, the pairing will be done.

How To Control These Earbuds? – Dual Mode

NOTE: The touch control area is placed on the top part of the body of the earbuds.

• Play or pause a song: Press the touch control area on the right earbud two times.
• Play the next song: While listening to music, press and hold the touch control area on the right earbud for about 2 seconds.
• Play the previous song: While listening to music, press and hold the touch control area on the left earbud for about 2 seconds.
• Answer an incoming call: Press the touch control area on any of the earbuds two times.
• End a current call: Press the touch control area on any of the earbuds two times.
• Reject an incoming call: Press and hold the touch control area on any of the earbuds for about 2 seconds.
• Activate the voice assistant: Press the touch control area on the left earbud two times.

Do These Earbuds Have An App?

Yeah! These earbuds work hand in hand with a specially made app called Soundcore, which is available in the Play Store and App Store. After opening the app and pairing the earbuds, you will not only be able to see the earbuds’ battery percentage, but four options will appear:

• Equalizer: You can configure the type of sound to adjust the quality and character of what you hear. Here, there are options like Acoustic, Bass Reducer, Classical, Podcast, and more.
• Controls: The earbuds controls are located here, and they can be modified, activated, and deactivated.
• Find Device: This part of the app allows you to create a special link between the earbuds and the app, where they can be located in case of loss.
• Gaming Mode: This function allows you to activate or deactivate the Game mode integrated into the earbuds.

The Earbuds’ Firmware Update

The user will be informed once the new version of firmware is detected when the earbuds get connected to the app. For the update, you have to make sure that the earbuds are placed in the charging case and the case remains open until the firmware update is completed.

NOTE: During the update, ensure the earbuds are being charged and avoid any usage.

Some Common Problems & Troubleshooting

Left/Right/One side of the earbuds has stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range.

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left/Right/One side of the earbuds has a low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

The microphone is not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbuds, so try replacing them or getting a refund.

The earbuds are not connecting to Windows/laptop/PC

If the earbuds are not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate the pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> Select Bluetooth.

2. Try uninstalling and reinstalling the Bluetooth driver, or updating the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

FAQs

We hope you now know how to operate the earbuds from the above Anker Soundcore P20i manual. Want to know anything about the earphones? Do not hesitate to ask in the comment section below.
