Anker Zolo Liberty | Earbuds Pairing Guide

The Anker Zolo Liberty earbuds come with a battery life of about 8 hours + up to 100 hours using the charging case, Bluetooth 4.2, two 5.5mm graphene dynamic drivers, support for the AAC and SBC audio codecs, the IPX5 sweat and dust-proof certification, and much more. Learn how to use these earbuds using this manual!

Anker Zolo Liberty | Pairing & Troubleshooting

How to Pair The Earbuds?

To iOS and Android phones

Step 1: Open the charging case and take the earbuds out. After that, they will turn on automatically. Also, you can press and hold the multifunction touch button on both earbuds for about 1 second

Step 2: Turn on Bluetooth on the desired device.

Step 3: Go to the device’s Bluetooth settings.

Step 4:  Select “ZOLO Liberty“. If a password is needed, type “0000”. After that, the pairing will be done.

To PC (Windows)

Step 1: Turn on Bluetooth on the desired device.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Open the charging case and take the earbuds out. After that, they will turn on automatically. Also, you can press and hold the multifunction touch button on both earbuds for about 1 second.

Step 6: Select “ZOLO Liberty“. If a password is needed, type “0000”. After that, the pairing will be done.

How to Wear?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

How to Turn On and Off?

Turn on: Open the charging case and take the earbuds out. After that, they will turn on automatically. Also, you can press and hold the multifunction touch button on both earbuds for about 1 second.

Turn off: Place the earbuds into the charging case. After that, the earbuds will turn automatically. Also, you can press and hold the multifunction touch button on both earbuds for about 5 seconds.

How to Control? / How to Operate? – Instructions

• Play or pause a song: Press the multifunction touch button on any of the earbuds one time.
• Play the next song: Press and hold the multifunction touch button on the right earbud for about 1 second.
• Play the next previous: Press and hold the multifunction touch button on the left earbud for about 1 second.
• Answer an incoming call: Press the multifunction touch button on any of the earbuds one time.
• End a current call: Press the multifunction touch button on any of the earbuds one time.
• Reject an incoming call: Press and hold the multifunction touch button on any of the earbuds for about 1 second.
• Transfer a call from the earbuds to the connected device: Press and hold the multifunction touch button on any of the earbuds for about 1 second.
• Switch between a held call and an active call: Press and hold the multifunction touch button on any of the earbuds for about 1 second.
• Activate the voice assistant: Press the multifunction touch button on any of the earbuds two times.

How to Activate The Mono Mode?

To activate or deactivate the mono mode in these earbuds, all you have to do is to pair the earbuds to the device and take out one of the earbuds from the charging case. It will start working by itself.

How to Charge The Earbuds?

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case and close the lid. The earbuds will start charging automatically.

Charging case

To charge the charging case, all you have to do is to connect the case to a USB charger or charging port with the included USB-A to C cable. It will start charging automatically.

How to Reset The Earbuds?

Step 1: Take the earbuds out of the charging case.

Step 2: Press and hold the multifunction touch button on both earbuds for about 5 seconds, or until a red light starts flashing on the earbuds.

Step 3: Press and hold the multifunction touch button on both earbuds for about 8 seconds, or until a pink light starts flashing on the earbuds.

Step 4: Place both earbuds into the charging case. The right earbud will automatically re-pair to the left earbud.

Step 5: Delete all “ZOLO Liberty” pairing information from the connected device. After that, the resetting will be done.

What Do The Lights Mean?

Earbuds

• A red light flashing while resetting: The earbuds are resetting.
• A pink light flashing while resetting: The earbuds are resetting.

Charging case

• One light flashing while charging: The case has less than 30% of battery.
• One light on and one flashing while charging: The case has between 30% and 70% of battery.
• Two lights on and one flashing while charging: The case has more than 70% of battery.
• All lights on while charging: The case is fully charged.
• One light on after shaking it: The case has less than 30% of battery.
• Two lights on after shaking it: The case has between 30% and 70% of battery.
• All lights on after shaking it: The case is fully charged.
• One light flashing with the earbuds inside: The earbuds have less than 30% of battery.
• One light on and one flashing with the earbuds inside: The earbuds have between 30% and 70% of battery.
• Two lights on and one flashing with the earbuds inside: The earbuds have more than 70% of battery.
• All lights on with the earbuds inside: The earbuds are fully charged.

Some Common Problems & Troubleshooting

Left / Right / One side of the earbuds has stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left / Right / One side of the earbuds has a low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

The microphone is not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbud, so try replacing them or get a refund.

The earbuds are not connecting to Windows/laptop/PC

If the earbuds are earbuds not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate the pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> select Bluetooth.

2. Try uninstalling and reinstalling the Bluetooth driver, or updating the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

FAQs

We hope you now know how to operate the earphone from the above Anker Zolo Liberty manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.
