Edifier W240TN Manual | Step-by-step, In-depth Guide

The Edifier W240TN have Bluetooth 5.3, a battery life of about 7 hours (with ANC on) and 8.5 hours (with ANC off), a combination of 6mm + 10mm dynamic drivers, SBC audio coding, the dust and sweat-proof IPX5 certification, and more. Learn how to use these earbuds with this new Edifier W240TN Manual!

If you want to give the original manual a look, you can do it here.

Edifier W240TN Specs Sheet

Model	Edifier W240TN
Weight	Earbuds: About 5.8 grams each Charging case: About 39.6 grams
Waterproof/IP ratings	IPX5
Bluetooth version	V5.3
Range/Distance	10 meters
Driver	6mm + 10mm
Audio Decoding	SBC
Connectivity Port/Charging Cable	Type-C
Speaker frequency response	20Hz – 20kHz
Battery Life	Earbuds: About 8.5 hours (ANC off)/Around 7 hours (ANC on) Charging case: About 17 hours (ANC off)/Around 14 hours (ANC on)
Charging Time	Earbuds: About 1 hour Charging case: About 1.5 hours
App support	Yes, Edifier Connect
Controls/Features	Play or pause music, play the next song, answer, end, and reject a call, voice assistant, ANC, Ambient mode
Accessories	Charging case, USB cable, user manual, ear tips
Price	Around 70 USD

Edifier W240TN Accessories

The earbuds come with the following accessories:

• Charging case.
• USB cable.
• User manual.
• Ear tips.

Edifier W240TN Manual | Pairing & Charging Instructions

How To Pair The Earbuds?

To iOS and Android phones

Step 1:  Open the lid of the charging case. After that, the earbuds will turn on automatically.

Step 2: Press and hold the button on the back of the charging case for about 3 seconds, until the lights on the front light up one by one from left to right in a circulating pattern.

Step 3: Turn on Bluetooth on the desired device.

Step 4: Go to the device’s Bluetooth settings.

Step 5: Select “EDIFIER W240TN”. If a password is needed, type “0000”.

After that, the lights will flash two times and then turn off, and the pairing will be done.

To PC (Windows)

Step 1: Turn on Bluetooth on the desired device.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Open the lid of the charging case. After that, the earbuds will turn on automatically.

Step 6: Press and hold the button on the back of the charging case for about 3 seconds, until the lights on the front light up one by one from left to right in a circulating pattern.

Step 7: Select “EDIFIER W240TN”. If a password is needed, type “0000”.

After that, the lights will flash two times and then turn off, and the pairing will be done.

How To Wear These Earbuds?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

How To Turn On And Off?

Turn on: Open the lid of the charging case. After that, the earbuds will turn on automatically.

Turn off: Place the earbuds into the charging case and close its lid. After that, the earbuds will turn off automatically.

How to Control? / How to Operate? – Instructions

NOTE: The multifunction touch button is placed on the top part of the body of the earbuds.

• Play or pause music: Press the multifunction touch button on any of the earbuds one time.
• Play the next song: Press the multifunction touch button on any of the earbuds two times.
• Answer an incoming call: Press the multifunction touch button on any of the earbuds one time.
• End a current call: Press the multifunction touch button on any of the earbuds one time.
• Reject an incoming call: Press and hold the multifunction touch button on any of the earbuds for about 2 seconds.
• Activate the voice assistant: Press the multifunction touch button on any of the earbuds three times.

How To Activate The ANC Mode?

To activate or deactivate the ANC mode in these earbuds, all you have to do is to press and hold the multifunction touch button on any of the earbuds for about 2 seconds.

How To Activate The Ambient Mode?

To activate or deactivate the ambient mode in these earbuds, all you have to do is to press and hold the multifunction touch button on any of the earbuds for about 2 seconds.

How To Activate The Mono Mode?

To activate or deactivate the mono mode in these earbuds, all you have to do is to pair the earbuds to the device and take out one of the earbuds from the charging case. It will start working by itself.

How To Charge The Earbuds?

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case and close the lid. The earbuds will start charging automatically.

Charging case

To charge the charging case, all you have to do is to connect the case to a USB charger or charging port with the included USB-A to C cable. It will start charging automatically.

What Do The Lights Mean?

Charging case

• Lights light up one by one from left to right in a circulating pattern: The earbuds are now ready to pair with any device.
• Lights flash two times and then turn off: The earbuds are not paired to the device.
• Lights are on while charging: The case is charging.
• Lights turn off while charging: The case is fully charged.
• Lights are on while charging with the earbuds inside: The earbuds are charging.
• Lights turn off while charging with the earbuds inside: The earbuds are charged.
• Lights light up one by one from left to center in a circulating pattern while resetting: The earbuds are resetting.
• Lights light up one by one from left to right in a circulating pattern while resetting: The earbuds are resetting.
• Lights flash two times and then turn off while resetting: The earbuds are resetting.

How To Reset These Earbuds?

Step 1:  Delete all pairing information regarding the “EDIFIER W240TN”.

Step 2: Open the lid of the charging case. After that, the earbuds will turn on automatically.

Step 3: Press and hold the button on the back of the charging case for about 3 seconds, until the lights on the front light up one by one from left to center in a circulating pattern, to then flash two times and turn off. This will make them re-enter the left and right connection and clear the pairing records.

Step 4: Turn off Bluetooth on the desired device.

Step 5: Turn on Bluetooth on the desired device.

Step 6: Go to the device’s Bluetooth settings.

Step 7: Select “EDIFIER W240TN”. If a password is needed, type “0000”.

After that, the lights on the front of the case light up one by one from left to right in a circulating pattern, to then flash two times and turn off. The pairing will be done.

A Guide To Edifier W240TN APP

The Edifier W240TN can be used with an application, called Edifier Connect. This application is available for iOS and Android devices.

• First page: On the first page, not only is the battery percentage that the earbuds have but there is also the ability to turn ANC and ambient sound mode on or off. Likewise, there are also the settings, where there is information about the earbuds, as well as some options for use and user manuals.
• Second page: On the second page, you will find information about the different products launched by Edifier, as well as blogs, news, and support in case of problems with the devices.
• Third page: On the third page, you will find general information about the application, as well as the devices with which it is compatible, FAQs, and more.

Some Common Problems & Troubleshooting

Left/Right/One side of the earbuds has stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left/Right/One side of the earbuds has a low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

The microphone is not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbuds, so try replacing them or getting a refund.

The earbuds are not connecting to Windows/laptop/PC

If the earbuds are not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate the pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> Select Bluetooth.

2. Try uninstalling and reinstalling the Bluetooth driver, or updating the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

FAQs

We hope you now know how to operate the earphone from the above Edifier W240TN Manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.

In case you want or need to contact the Edifier company, all your information can be found on its Contact Us page, where you can find numbers and emails available for several countries! Also, they have a Support page, with FAQs and information about their products!
