Edifier X3 TO-U Manual | Pairing & Charging Instructions 2021

Having Bluetooth version 5.0, being sweat and rain resistant thanks to its IPX5 certification, providing 5 to 6 hours listening on a full charge, having a Qualcomm chip, and more, the Edifier X3 TO-U are a great option when talking about earbuds. Today we are going to teach you how to use them in this new Edifier X3 TO-U Manual.

Edifier X3 TO-U Manual | Everything You Need To Know

Edifier X3 TO-U Manual | How to Pair / Connect?

To iOS and Android phones

Step 1: Take the earbuds out of the charging case. They will turn on and pair to each other automatically.

Step 2: Press and hold the touch button of the left earbud to enter the pairing mode. After this, red and blue lights will flash quickly.

Step 3: Turn on the Bluetooth on the desired device.

Step 4: Go to the Bluetooth settings.

Step 5: Select the “Edifier X3 TO-U”. If a password is needed, type “0000”.

Step 6: After that, blue lights will flash quickly on the earbuds and the pairing will be done.

To PC (Windows)

Step 1: Turn on Window’s Bluetooth.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Click on Bluetooth.

Step 6: Take the earbuds out of the charging case. They will turn on and pair to each other automatically.

Step 7: Press and hold the touch button of the left earbud to enter the pairing mode. After this, red and blue lights will flash quickly

Step 8: The earbuds by the name “Edifier X3 TO-U” will appear on the settings.

Step 9: Select. After that, blue lights will flash quickly on the earbuds and the pairing will be done.

Edifier-X3-TO-U-Manual-1
Credits: Scarbir

Edifier X3 TO-U Manual | How to Activate Mono Mode?

The earbuds go into stereo mode automatically after being paired with each other. To enter mono mode, all you have to do is to place one of the earbuds into the charging case, and the other one will enter mono mode automatically.

Edifier X3 TO-U Manual | How to Charge?

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case and close the lid. The earbuds will start charging automatically.

Charging Case

To charge the charging case, all you have to do is plug a 5V USB Type-C cable into the port on the charging case. It will start charging automatically.

Edifier X3 TO-U Manual | How To Turn On And Off?

Turn on: Take the earbuds out of the charging case. They will turn on automatically.

Turn off: Place the earbuds into the charging case. They will turn off automatically.

Edifier-X3-TO-U-Manual-2
Credits: Scarbir

How to Control? / How to Operate? – Instructions

  • Play or pause music: Click the touch button on any of the earbuds once.
  • Play the next song: Click the touch button on any of the earbuds twice.
  • Play the previous song: Click the touch button on any of the earbuds three times.
  • Answer an incoming call: Click the touch button on any of the earbuds once.
  • End a call: Click the touch button on any of the earbuds once.
  • Reject an incoming call: Press and hold the touch button on any of the earbuds.
Edifier-X3-TO-U-Manual-3

Edifier X3 TO-U Manual | LED Light Status

Earbuds

  • Red and blue lights flashing quickly: Pairing mode.
  • Blue light flashing slowly: Paired successfully.
  • Red light flashing: Low battery.
  • Red light flashing slowly: Earbuds charging.
  • Red light turns off: Earbuds fully charged.

Charging case

  • Light flashing quickly: Low battery.
  • Light on when charging: Case charging.
  • Light turns off: Case fully charged.

Edifier X3 TO-U Manual | How to Reset?

Step 1: Take the earbuds out of the charging case.

Step 2: Press the touch button on both earbuds for 8 seconds.

Step 3: After that, the resetting will be done.

Edifier-X3-TO-U-Manual-5

Some Common Earbuds Problems & Troubleshooting

Left / Right / One side of the earbuds have stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory reset the earbuds.

3. Check if the earbuds are operating within a normal working range

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left / Right / One side of the earbuds has low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory reset the earbuds.

Microphone not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbud, so try replacing them or get a refund.

Edifier X3 TO-U earbuds not connecting to Windows/laptop/PC

If the earbuds are earbuds not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> elect Bluetooth,

2. Try uninstalling and reinstalling the Bluetooth driver, or update the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds as said in the pairing section above.

Edifier-X3-TO-U-Manual-d
Credits: Awaqa

FAQs

Are the Edifier X3 TO-U waterproof?

These earbuds have the IPX5 dust-and-waterproof certification, meaning there are no worries when using them for exercise or outdoors.

Do Edifier X3 TO-U have low latency/gaming mode?

No, the Edifier X3 TO-U don’t have a low latency or gaming mode.

Does Edifier X3 TO-U have a microphone?

Yes, the Edifier X3 TO-U have an integrated microphone.

How to know when Edifier X3 TO-U are fully charged?

When the Edifier X3 TO-U are fully charged, the red LED light on the earbuds turns off.

Can Edifier X3 TO-U connect to PC and Laptop?

Yes, the Edifier X3 TO-U can connect to PCs, Laptops and Tablets.

We hope you now know how to operate the earphone from the above Edifier X3 TO-U Manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.

In case you want or need to contact the Edifier company, all your information can be found on its Contact Us page, where you can find numbers and emails available for several countries! Also, they have a Support page, with FAQs and information about their products!
