Fiil CC Nano Manual | Step-by-step Pairing & Troubleshooting

The Fiil CC Nano comes with up to 30 hours of battery life, dual-mic beamforming with A.I. Algorithm ENC, a Low Latency mode for gaming, videos, and music, Bluetooth 5.2, a specialized app, and much more. Learn how to use them with this new Fiil CC Nano Manual.

Fiil CC Nano Manual | Pairing & Charging Instructions

Fiil CC Nano Manual | How to Pair / Connect?

To iOS and Android phones

Step 1: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically. Also, you can press and hold the multifunction touch button on both earbuds for about 2 seconds.

Step 2: Go to the device’s Bluetooth settings.

Step 3: Select “Fiil CC Nano”. If a password is needed, type “0000”.

Step 4: After that, the pairing will be done.

To PC (Windows)

Step 1: Turn on Window’s Bluetooth.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically. Also, you can press and hold the multifunction touch button on both earbuds for about 2 seconds

Step 6: Select “Fiil CC Nano”. If a password is needed, type “0000”.

Step 7: After that, the pairing will be done.

Fiil-CC-Nano-Manual-1

Fiil CC Nano Manual | How to Wear?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

Fiil CC Nano Manual | How to Turn On and Off?

Turn on: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically. Also, you can press and hold the multifunction touch button on both earbuds for about 2 seconds.

Turn off: Place the earbuds into the charging case and close its lid. After that, the earbuds will turn off automatically.

Fiil-CC-Nano-Manual-2

How to Control? / How to Operate? – Instructions

Easy Mode

  • Play or pause music: Press the multifunction touch button on the right earbud two times.
  • Answer an incoming call: Press the multifunction touch button on the left earbud two times.
  • End a current call: Press the multifunction touch button on the left earbud two times.
  • Reject an incoming call: Press and hold the multifunction touch button on the right earbud for about 1.5 seconds.
  • Activate the voice assistant: Press and hold the multifunction touch button on the left earbud for about 1.5 seconds.

Full Control Mode (that you can activate using the app)

  • Play the next song: Press the multifunction touch button on the right earbud one time.
  • Play the previous song: Press the multifunction touch button on the right earbud three times
  • Turn the volume up: Press the multifunction touch button on the left earbud one time.
  • Turn the volume down: Press the multifunction touch button on the left earbud three times.
Fiil-CC-Nano-Manual-3

Fiil CC Nano Manual | How to Activate Low Latency Mode?

To activate or deactivate the ANC mode in the Fiil CC Nano, all you have to do is to use the specialized app and turn it on.

Fiil CC Nano Manual | How to Activate Mono Mode?

To activate or deactivate the mono mode in the Fiil CC Nano, all you have to do is to pair the earbuds to the device and take out one of the earbuds from the charging case. It will start working by itself.

Fiil CC Nano Manual | How to Charge?

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case and close the lid. The earbuds will start charging automatically.

Charging case

To charge the charging case, all you have to do is to connect the case to a USB charger or charging port with the included USB-A to C cable. It will start charging automatically.

Fiil-CC-Nano-Manual-4

Fiil CC Nano Manual | LED Light Status

Earbuds

  • A light turns on when the earbuds are placed on the case: The earbuds are charging.
  • Said light turns off: The earbuds are fully charged.

Charging case

  • The logo turns on when the earbuds are placed on the case: The earbuds are charging.

A Guide To Fiil CC Nano APP

The Fiil CC Nano can be used with an application, called fiil+. This application is available for iOS and Android devices.

  • First page: On this first page, we will find the home page. Here, there will be the possibility of logging into the application through different social networks.
  • Second page: On the second page, we are going to get the percentage of the battery of the earbuds that are connected.
  • Third page: On the third page, we will have the possibility to configure the equalizer.
  • Fourth page: On the fourth page, there is a special function, and it is about choosing between different sound effects available for the sound provided by the earbuds.
  • Fifth page: On the fifth page, there is a special feature, and it is about being able to place a 3D effect on the songs that are heard.

In addition to all that, there are also different user manuals available, as well as the settings of the application and the earbuds.

Some Common Earbuds Problems & Troubleshooting

Left / Right / One side of the earbuds have stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left / Right / One side of the earbuds has low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

Microphone not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbud, so try replacing them or get a refund.

Fiil CC Nano earbuds not connecting to Windows/laptop/PC

If the earbuds are earbuds not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> elect Bluetooth,

2. Try uninstalling and reinstalling the Bluetooth driver, or update the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds as said in the pairing section above.

Fiil-CC-Nano-Manual-5

FAQs

Are the Fiil CC Nano waterproof?

No, the Fiil CC Nano are not waterproof (IPX6 and up). They have a rating of IPX4, which means they’re splash and sweat-resistant.

Does Fiil CC Nano have a microphone?

Yes, the Fiil CC Nano has integrated microphones.

Do Fiil CC Nano have low latency/gaming mode?

Yes! The Fiil CC Nano have a low latency/gaming mode.

How to know when Fiil CC Nano are fully charged?

When the earbuds are charging, a light on the charging case and earbuds turns on. When fully charged, those lights turn off.

Can Fiil CC Nano connect to PC and Laptop?

Yes, the Fiil CC Nano can connect to PCs, laptops and tablets.

We hope you now know how to operate the earphone from the above Fiil CC Nano Manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.
