Foycoy C17 Manual | How Can You Use These Earbuds?

The Foycoy C17 earbuds come with specs such as the amazing IPX7 waterproof certification, Bluetooth 5.3 technology with a working range of 10 meters, about 8 hours of battery life + 82 hours using the charging case, 13mm drivers in each earbud, mono mode support, and much more. Learn how to use these earbuds using this Foycoy C17 manual!

If you are interested in purchasing these earbuds, you can easily do it using the Amazon online store. Also, in case you are interested in giving the original manual a look, you can do it here.

Foycoy C17 Specs Sheet

Model	Foycoy C17
Waterproof/IP ratings	IPX7
Bluetooth version	V5.3
Range/Distance	10 meters
Connectivity Port/Charging Cable	Type-C
Audio Decoding	SBC
Driver	13mm
Speaker frequency response	20Hz – 20kHz
Battery Life	Earbuds: About 8 hours Charging case: About 82 hours
Charging Time	Earbuds: Around 2 hours Charging case: About 2 hours
App Support	No
Controls/Features	Play and pause a song, play the next and previous song, answer, end, and reject a call, voice assistant, turn the volume up and down
Accessories	Charging case, USB cable, user manual, ear tips
Price	Around 55 USD

Foycoy C17 Accessories

The earbuds come with the following accessories:

• Charging case.
• USB cable.
• User manual.
• Ear tips.

Foycoy C17 Manual | Step-by-step User Guide

How To Pair The Earbuds? – Dual Mode

To Android And iOS Devices

Step 1: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically and pair with each other.

After that, they will be now ready to pair with any device.

Step 2: Unlock the desired device.

Step 3: Go to the device’s settings.

Step 4: Turn on Bluetooth on the desired device.

Step 5: Search for a new device.

Step 6: Select the C17 earbuds. If a password is needed, type “0000” or “1234”.

After that, the pairing will be done.

To Windows (PC)

Step 1: Turn on the Window’s Bluetooth.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Click on Bluetooth.

Step 6: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically and pair with each other.

After that, they will be now ready to pair with any device.

Step 7: Select the C17 earbuds. If a password is needed, type “0000” or “1234”.

After that, the pairing will be done.

How To Pair The Earbuds? – Mono Mode

Mode 1

Step 1: Pair both earbuds with the device.

Step 2: When in dual mode, place one of the earbuds into the charging case. The other one will continue working by itself.

Mode 2

Step 1: Take only one of the earbuds out of the charging case. It will enter pairing mode.

Step 2: Search for a new device.

Step 3: Select the C17 earbud. If a password is needed, type “0000” or “1234”.

After that, the pairing will be done.

How To Control These Earbuds?

NOTE: The touch control area is placed on the upper part of the body of the earbuds.

• Play or pause a song: Press the touch control area on any of the earbuds two times.
• Play the next song: While listening to music, press the touch control area on the right earbud three times.
• Play the previous song: While listening to music, press the touch control area on the left earbud three times.
• Turn the volume up: Press and hold the touch control area on the right earbud.
• Turn the volume down: Press and hold the touch control area on the left earbud.
• Answer an incoming call: Press the touch control area on any of the earbuds two times.
• End a current call: Press the touch control area on any of the earbuds two times.
• Reject an incoming call: Press and hold the touch control area on any of the earbuds for about 2 seconds.
• Activate the voice assistant: Press the touch control area on any of the earbuds three times.

NOTE 2: In single (mono) mode, the right earbud only supports playing the next song and turning the volume up, while the left earbud only supports playing the previous song and turning the volume down.

How To Reset And Re-Pair These Earbuds?

Step 1: Delete the C17 earbuds from the devices’ Bluetooth list.

Step 2: Turn off Bluetooth.

Step 3: Take the earbuds out of the case.

Step 4: Press the multifunction button on both earbuds five times. A red and blue light will flash one time, and then it will turn red for 2 seconds.

This will reset the earbuds.

Step 5: Place both earbuds into the charging case to get charged for 1 minute.

Step 6: Turn on Bluetooth.

Step 7: Search for a new device.

Step 8: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically and pair with each other.

After that, they will be now ready to pair with any device.

Step 9: Select the C17 earbuds. If a password is needed, type “0000” or “1234”.

After that, the pairing will be done.

How To Charge The Earbuds?

Earbuds

To charge the earbuds, all you have to do is place them into the charging case. The earbuds will start charging automatically.

Charging Case

To charge the charging case, all you have to do is connect the case to a USB charger or charging port. It will start charging automatically. Also, it can be charged using a wireless charger.

What Do The Lights Mean?

Earbuds

• A red light on while on the charging case: The earbuds are charging.
• Said red light turns off while on the charging case: The earbuds are fully charged.
• A red and blue light flashes one time, and then turns red for 2 seconds while resetting: The earbuds are resetting.

Charging Case

• 0 to 99 appears on the display while charging: The case is charging.
• A 100 appears on the display while charging: The case is fully charged.
• Flashing up and down design with the earbuds inside: The earbuds are charging.
• Said flashing lights turn off with the earbuds inside: The earbuds are fully charged.

How To Wear These Earbuds?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth and the ear hooks are placed comfortably behind the ear.

How To Turn On And Off?

Turn On

Automatically: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically.

Manually: Press and hold the touch control area on both earbuds for about 2 seconds. After that, the earbuds will turn on.

Turn Off

Automatically: Place the earbuds into the charging case. After that, the earbuds will turn off automatically.

Manually: Press and hold the touch control area on both earbuds for about 5 seconds. After that, the earbuds will turn off.

The Earbuds’ Voice Prompts

• Low battery: The earbuds have less than 10% of battery.
• Power off: The earbuds turn off.

Do These Earbuds Have An App?

No! Sadly, these earbuds don’t have app support.

Some Common Problems & Troubleshooting

Left/Right/One side of the earbuds has stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range.

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left/Right/One side of the earbuds has a low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

The microphone is not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbuds, so try replacing them or getting a refund.

The earbuds are not connecting to Windows/laptop/PC

If the earbuds are not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate the pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> Select Bluetooth.

2. Try uninstalling and reinstalling the Bluetooth driver, or updating the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

FAQs

We hope you now know how to operate the earbuds from the above Foycoy C17 manual. Want to know anything about the earphones? Do not hesitate to ask in the comment section below.
