JBL LIVE 300 Manual | Step-by-step Guide

The JBL LIVE 300 have Bluetooth 5.0, the IPX5 sweat and dust-proof certification, A2DP 1.3, AVRCP 1.5, and HFP 1.6 codecs, a Passive Noise Reduction feature, up to 20 hours of battery life using the charging case, and more. Learn how to use them with this new JBL LIVE 300 Manual.

If you are interested in purchasing these earbuds, you can easily do it using the JBL official website. Also, if you want to give the original manual a look, you can do it here.

JBL LIVE 300 Specs Sheet

ModelJBL LIVE 300
WeightEarbuds: 6.2 grams each
Charging case: 55.6 grams
Waterproof/IP ratings  IPX5
Bluetooth version          V5.0
Range/Distance10 meters
Driver5.6mm
Audio DecodingSBC, AAC
Connectivity Port/Charging CableType-C
Speaker frequency response20Hz – 20kHz
Battery Life       Earbuds: About 6 hours
Charging case: About 14 hours
Charging Time  Earbuds: About 2 hours
Charging time: About 2.5 hours
App Support     No
Controls/Features         Play or pause music, turn the volume up and down, play the next and previous song, answer, end, and reject a call, Ambient Aware mode, TalkThru mode
Accessories       Charging case, user manual, USB cable, ear tips, ear hooks
PriceAbout 75 USD

JBL LIVE 300 Accessories

The earbuds come with the following accessories:

  • Charging case.
  • User manual.
  • USB cable.
  • Ear tips.
  • Ear hooks.
jbl-live-300-manual-box

JBL LIVE 300 Manual | Pairing & Charging Guide

How To Pair The Earbuds?

To iOS and Android phones

Step 1: Open the lid of the charging case. After that, a white light will flash two times, and the earbuds will turn on automatically.

When a blue and white light starts flashing on the charging case, that means that they will be ready to pair with any device. If the earbuds don’t enter pairing mode automatically, all you have to do is to press the multifunction touch button on the right earbud two times, and then press and hold for 5 seconds.

Step 2: Turn on Bluetooth on the desired device.

Step 3: Go to the device’s Bluetooth settings.

Step 4: Select “JBL LIVE300TWS”. If a password is needed, type “0000”.

After that, a blue light will start flashing slowly and the pairing will be done.

To PC (Windows)

Step 1: Turn on Bluetooth on the desired device.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Open the lid of the charging case. After that, a white light will flash two times, and the earbuds will turn on automatically.

When a blue and white light starts flashing on the charging case, that means that they will be ready to pair with any device. If the earbuds don’t enter pairing mode automatically, all you have to do is to press the multifunction touch button on the right earbud two times, and then press and hold for 5 seconds.

Step 6: Select “JBL LIVE300TWS”. If a password is needed, type “0000”.

After that, a blue light will start flashing slowly, and the pairing will be done.

JBL-LIVE-300-Manual-1
Credits: JBL

How To Wear These Earbuds?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

How To Turn On And Off?

Turn on: Open the lid of the charging case. After that, a white light will flash two times, and the earbuds will turn on automatically.

Turn off: Place the earbuds into the charging case and close its lid. After that, the earbuds will turn off automatically.

JBL-LIVE-300-Manual-2
Credits: JBL

How to Control? / How to Operate? – Instructions

NOTE: The multifunction touch button is placed on the top part of the body of the earbuds.

  • Play or pause music: Press the multifunction touch button on the right earbud one time.
  • Play the next song: Press the multifunction touch button on the right earbud two times.
  • Play the previous song: Press the multifunction touch button on the right earbud three times.
  • Turn the volume up: Swipe right on the multifunction touch button on the right earbud.
  • Turn the volume down: Swipe left on the multifunction touch button on the right earbud.
  • Answer an incoming call: Press the multifunction touch button on the right earbud two times.
  • End a current call: Press the multifunction touch button on the right earbud two times.
  • Mute or unmute the microphone: Press the multifunction touch button on the right earbud one time, and press and hold for 1 second.
  • Activate the voice assistant: Swipe left on the multifunction touch button on the left earbud.
  • Activate or deactivate the Ambient Aware feature: Swipe left on the multifunction touch button on the left earbud.
  • Activate or deactivate the Talkthru feature: Swipe left on the multifunction touch button on the left earbud.

How To Activate The Mono Mode?

To activate or deactivate the mono mode in these earbuds, all you have to do is to pair the earbuds to the device and take out one of the earbuds from the charging case. It will start working by itself.

JBL-LIVE-300-Manual-3
Credits: JBL

How To Charge The Earbuds?

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case and close the lid. The earbuds will start charging automatically.

Charging case

To charge the charging case, all you have to do is to connect the case to a USB charger or charging port with the included USB-A to C cable. It will start charging automatically.

JBL-LIVE-300-Manual-4
Credits: JBL

How To Reset These Earbuds?

Step 1: Delete all “JBL LIVE300TWS” pairing information from the connected device.

Step 2: Place the earbuds into the charging case and keep the lid open.

Step 3: Press and hold the button inside the charging case for about 5 seconds. After that, a red light will light up on the case, and resetting will be done.

JBL-LIVE-300-Manual-5
Credits: JBL

What Do The Lights Mean?

Earbuds

  • A white light flashes two times: The earbuds turn on.
  • A blue and white light flashing: The earbuds are ready to pair with any device.
  • A blue light flashing slowly: The earbuds are paired.
  • A blue light flashing quickly: The connection has failed.
  • A white light flashing slowly: The earbuds have a low battery.

Charging case

  • A blue and white light flashing: The earbuds are ready to pair with any device.
  • A blue light flashing quickly: The connection has failed.
  • A red light flashing slowly while connected to the charger: The case is charging.
  • Said light turns off while connected to the charger: The case is fully charged.
  • A red light flashing quickly with the earbuds inside while connected to the charger: The case is charging.
  • Said red light turns off with the earbuds inside while connected to the charger: The case is fully charged.
  • A white light flashing slowly with the earbuds inside: The earbuds are charging.
  • Said white light turns off with the earbuds inside: The earbuds are fully charged.
  • A red light on while resetting: The earbuds are resetting.
JBL-LIVE-300-Manual-6
Credits: JBL

Some Common Problems & Troubleshooting

Left/Right/One side of the earbuds has stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left/Right/One side of the earbuds has a low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

The microphone is not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbuds, so try replacing them or getting a refund.

The earbuds are not connecting to Windows/laptop/PC

If the earbuds are not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate the pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> Select Bluetooth.

2. Try uninstalling and reinstalling the Bluetooth driver, or updating the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

JBL-LIVE-300-Manual-7
Credits: SoundGuys

FAQs

Are the JBL LIVE 300 waterproof?

No, the JBL LIVE 300 are not waterproof (IPX6 and up). They have a rating of IPX5, which means they’re protected against some water projected from a nozzle.

Do the JBL LIVE 300 have a microphone?

Yes, the earbuds come with integrated microphones.

Do the JBL LIVE 300 have a low latency/gaming mode?

No, these earbuds don’t have a low latency/gaming mode.

Can the JBL LIVE 300 connect to PC and Laptop?

Yes, these earbuds can connect to PCs, laptops, and even tablets.

Are the JBL LIVE 300 noise-canceling?

No! These earbuds don’t come with noise cancellation technology.

How to know when the JBL LIVE 300 are fully charged?

When the earbuds are charging, a white light is flashing on the charging case. When fully charged, the light turns off.

We hope you now know how to operate the earphone from the above JBL LIVE 300 Manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.
