How To Pair The JBL Reflect Mini NC Earbuds? | User Guide

The JBL Reflect Mini NC earbuds come with the amazing IPX7 waterproof certification, a 6mm dynamic driver, Bluetooth 5.1, a working range of about 10 meters, up to 6 hours of battery life, and much more. Learn how to use these earbuds using this manual!

JBL Reflect Mini NC Earbuds | All You Need To Know

How to Pair The Earbuds?

To iOS and Android Phones

Step 1: Open the lid of the charging case. After that, a blue light will start flashing on the earbuds, and they will turn on automatically.

When a blue and red light starts flashing on the earbuds, and a blue light flashes quickly on the charging case, it means that they are now ready to pair with any device.

NOTE: If the earbuds don’t enter pairing mode automatically, then press the multifunction touch button on both earbuds one time, and then press for a couple of seconds.

Step 2: Turn on Bluetooth on the desired device.

Step 3: Go to the device’s Bluetooth settings.

Step 4: Select “JBL REFLECT MINI NC”. If a password is needed, type “0000”. After that, a blue light on the earbuds and charging case will be flashing slowly, and the pairing will be done.

To PC (Windows)

Step 1: Turn on Bluetooth on the desired device.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Open the lid of the charging case. After that, a blue light will start flashing on the earbuds, and they will turn on automatically.

When a blue and red light starts flashing on the earbuds, and a blue light flashes quickly on the charging case, it means that they are now ready to pair with any device.

NOTE: If the earbuds don’t enter pairing mode automatically, then press the multifunction touch button on both earbuds one time, and then press for a couple of seconds.

Step 6: Select “JBL REFLECT MINI NC”. If a password is needed, type “0000”. After that, a blue light on the earbuds and charging case will be flashing slowly, and the pairing will be done.

How to Wear?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

How to Turn On and Off?

Turn on: Open the lid of the charging case. After that, a blue light will start flashing on the earbuds, and they will turn on automatically.

Turn off: Place the earbuds into the charging case and close its lid. After that, the earbuds will turn off automatically.

How to Control? / How to Operate? – Instructions

• Play or pause music: Press the multifunction touch button on the right earbud one time.
• Play the next song: Press the multifunction touch button on the right earbud two times.
• Play the previous song: Press the multifunction touch button on the right earbud three times.
• Answer an incoming call: Press the multifunction touch button on any of the earbuds two times.
• End a current call: Press the multifunction touch button on any of the earbuds two times.
• Mute or unmute the microphone: Press and hold the multifunction button on any of the earbuds for about 2 seconds.
• Activate the voice assistant: Press and hold the multifunction button on any of the earbuds for about 2 seconds.

How to Activate The ANC And Ambient Aware Modes?

To activate, deactivate, and change between the ANC and ambient aware modes in these earbuds, all you have to do is to press the multifunction touch button on the left earbud one time.

How to Activate The TalkThru Mode?

To activate or deactivate the TalkThru mode in these earbuds, all you have to do is to press the multifunction touch button on the left earbud two times.

How to Charge The Earbuds?

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case and close the lid. The earbuds will start charging automatically.

Charging case

To charge the charging case, all you have to do is to connect the case to a USB charger or charging port with the included USB-A to C cable. It will start charging automatically.

What Do The Lights Mean?

Earbuds

• A blue light flashing: The earbuds turn on.
• A blue and red light flashing: The earbuds are ready to pair with any device.
• A blue light flashing slowly: The earbuds are now connected.
• A red light flashing: The earbuds have a low battery.

Charging case

• A blue light flashing quickly: The earbuds are ready to pair with any device.
• A blue light flashing slowly: The earbuds are now connected.
• A blue light on while resetting: The earbuds resetting is done.
• The first part of the LED stripe on: The case has a low battery.
• Half of the LED stripe on while charging: The case is charging.
• The LED stripe turns off while charging: The case is fully charged.
• The left part the LED stripe on with the earbuds inside: The left earbud is charging.
• The right part the LED stripe on with the earbuds inside: The right earbud is charging.
• The LED stripe turns off with the earbuds inside: The earbuds are fully charged.

How to Reset The Earbuds?

Step 1: Delete all “JBL REFLECT MINI NC” pairing information from the connected device.

Step 2: Place the earbuds into the charging case and keep the lid open.

Step 3: Press and hold the button on the back of the charging case for about 5 seconds, until a blue light turns on the case. After that, the resetting will be done.

A Guide To JBL Reflect Mini NC APP

The JBL Reflect Mini NC can be used with an application, called JBL HEADPHONES. This application is available in the Apple Store and in the Play Store for iOS and Android devices. When opening the application, the first thing we have to do is connect our earbuds, and after that, three specific pages:

• First page: This is the first page of this application, and you will be able to see the connected device.
• Second page: On the second page, we will not only find the connected device, but also the battery percentages of both earbuds. Also, you will find options like enabling or disabling the ANC, enabling or disabling the Ambient Sound Control, and the Smart Audio and Video feature.
• Third page: On the third and last page, you will be able to configure the controls of the earbuds, enable or disable the auto turn-off of the earbuds, the Find My Earbud feature, and information about the earbuds, and the firmware version.

Some Common Problems & Troubleshooting

Left / Right / One side of the earbuds have stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left / Right / One side of the earbuds has a low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

The microphone is not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbud, so try replacing them or get a refund.

The earbuds are not connecting to Windows/laptop/PC

If the earbuds are earbuds not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate the pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> select Bluetooth.

2. Try uninstalling and reinstalling the Bluetooth driver, or updating the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

FAQs

We hope you now know how to operate the earphone from the above JBL Reflect Mini NC manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.
