JBL Tune 125TWS Manual | Step-by-Step User Guide 2021

In the world of technology, there are a large number of products, which can be used to improve our lives at home or for personal and recreational use. Among the many products that are currently available, we have the earbuds, and here we have talked about some of them, as well as the Skullcandy Indy Anc. In this article, we are going to show you the user manual of one of these products, the JBL Tune 125TWS, as well as the correct way to use them in this new JBL Tune 125TWS Manual.

JBL Tune 125TWS Manual | All you need to know about!

JBL Tune 125TWS Manual – How To Pair / Pairing Mode?

Step 1: Remove both headphones from their charging case. By doing this, they will automatically turn on and connect to each other.

Step 2: Activate the Bluetooth pairing function on the device you want to pair with the headphones.

Step 3: In the list of available devices, find and select “JBL Tune 125TWS“.

Step 4: In case a code or PIN is required for pairing, enter “0000“, “1111” or “1234”.

JBL Tune 125TWS Manual – How to charge?

To charge the JBL Tune 125TWS, all you have to do is place the earbuds in their charging case and close it, so that they start charging automatically. Having said that, the buds can be charged while the case is connected to a power source, and charging takes around 2 hours.

JBL Tune 125TWS Manual – Controls

  • Turn on: Press the physical button for 2 seconds.
  • Turn off: Press the physical button for seconds.
  • Play/pause music: Press the physical button on the right earbud once.
  • Answer/end a call: Press the physical button on the right earbud once.
  • Turn on / off the mic during a call: Press the physical button on the right earbud for 2 seconds.
  • Activate Siri, Google Assistant, and Bixby Assistant: Press the physical button on the right earbud twice.
  • Play next song: Press the physical button on the left earbud once.
  • Play previous song: Press the physical button on the left earbud twice.

Controls on mono mode (using only one of the earbuds)

  • Play/pause music: Press the physical button once.
  • Answer/end a call: Press the physical button once.
  • Turn on / off the mic during a call: Press the physical button for 2 seconds.
  • Activate Siri, Google Assistant, and Bixby Assistant: Press the physical button twice.

JBL Tune 125TWS Manual – How to Connect To PC?

Step 1: Power on the PC.

Step 2: Turn on the earbuds, and they automatically will go into pairing mode.

Step 3: On your computer, go to the Bluetooth settings and select “Add Bluetooth” or other devices.

Step 4: From the list of available Bluetooth devices, select the “JBL Tune 125TWS“, and then click Done when it connects.

While connected, “Paired” appears below the product name in the computer Bluetooth settings.

JBL Tune 125TWS Manual - How to Connect To PC?

JBL Tune 125TWS Manual – How to Connect to iPhone/iOS?

Step 1: Remove both headphones from their charging case. By doing this, they will automatically turn on and connect to each other.

Step 2: Go to Settings and then Bluetooth. Turn on Bluetooth.

Step 3: Look for the “JBL Tune 125TWS” under “OTHER DEVICES” and tap on it to connect.

Step 4: In case a code or PIN is required for pairing, enter “0000“, “1111” or “1234”.

JBL Tune 125TWS Manual – How to factory reset earbuds?

Step 1: Connect the charging case to power.

Step 2: Place the earbuds in the charging case.

Step 3: Close the charging case lid for 5 seconds, then open the lid.

Step 4: In the charging case, press and hold the physical button on the earbuds for 30 seconds and then release it.

Step 5: On the device that was previously connected to your product, go to the device Bluetooth settings and Remove or Forget the earbuds from the device’s Bluetooth memory.

Step 6: Reconnect your product to the device.

JBL Tune 125TWS Manual – How to wear?

Step 1: Make sure to choose the ear tip that best suits your ear, so that placing the earbuds is easier and more comfortable.

Step 2: Insert the earbud so the ear tip gently rests at the opening of your ear canal.

Step 3: Slightly rotate the earbud back until the ear tip creates a comfortable seal at your ear canal.

Step 4: Having placed it in the ear opening, make sure that the earbud is positioned horizontally.

Step 5: Repeat steps 1 to 4 to insert the other earbud.

JBL Tune 125TWS Manual - How to wear?

Troubleshooting and Issues

JBL Tune 125TWS not charging

If the earbuds are not charging, then look in the charge port of the charging case and blow or pick out any possible dust that may be causing an issue also look in the port for any damage or if it is loose. If that’s not the case, then make sure that de earbuds are positioned correctly on the charging case.

JBL Tune 125TWS not pairing

The device to be connected might be in power-saving or sleep mode and, therefore, the earbuds will not connect. Double-check to ensure that those modes are turned off.

JBL Tune 125TWS one side not working (left or right)

In case one of the two earbuds is not working, the following can be done:

  • Check the side balance.
  • Check if the earbuds are on mono or stereo mode (only one of the earbuds will work).
  • Reconnect Bluetooth.
  • Reset the earbuds.

Troubleshooting and Issues

FAQ

Are the JBL Tune 125TWS waterproof?

The JBL Tune 125TWS doesn't have any IPX rating, so they are not waterproof.

Are the JBL Tune 125TWS noise cancelling?

No, they don't have a noise cancellation feature.

JBL Tune 125TWS volume control

You can volume up or down by clicking the volume button at the side of your smart device, but not on the earbuds.

What's the battery life of JBL Tune 125TWS?

According to the company, the earphones have a battery life of about 8 hours on a single charge.

What's the pairing PIN code required to connect JBL Tune 125TWS?

0000, 1111, or 1234.

Here’s a video of quick fix of left earbud not working:

JBL Tune 125TWS – Warnings

  1. Never dismantle or refit the product to avoid malfunction or fire hazards.
  2. Keep away from corrosive liquids to avoid damages to the product.
  3. Keep away from extreme ambient temperatures below -10C° or above 60°C.
  4. Keep away from children and pets.
  5. Never touch the earbuds with sharp objects, otherwise, it will easily cause scratches.
  6. Don’t use the product in thunderstorm weather to avoid malfunction or electric shock.
  7. If it has not been used for more than a month, please charge and maintain it in time to ensure that it is safe.

We hope you now know how to operate the earphone from the above JBL Tune 125TWS Manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.

  1. when i charge them the case (all three dots) start blinking. they turn on, go brighter, then go back and forth between brighter and dimmer. what does that mean?

  2. help when I set up the earbuds I accidentally entered a code and didnt read and I have used the code, now i am trying to reset the password but I have no idea how to. anyone have any idea how to reset the passcode of the tune 125

  3. right earbud stopped working. tried everything listed to resolve problem, but nothing seems to work.

    1. Having the same problem with my left one. Tried factory reset not can’t get it to connect to Bluetooth.

  4. The right bud is connected but the sound is super quiet while the left works just fine. Loud as can be…. I’ve reset them several times. Disconnected and reconnected several times….

    1. You need to clean ear wax out of the ear buds… it has clogged the sound port. Look YouTube videos on how to do it with out damaging units

    1. Try turning them off, while you are pressing the button to turn them back on – Hold till they blink white and blue. then let go- computer should pair automatically at this time. * Insure both earbuds are out of the case and fully charged. Turn off the bluetooth on your phone, if you are still paired and connected to your phone they will not connect to the laptop.

    2. When trying to connect do the ear buds, does the device name come up as Tune125TWSLE?,

      It should display as Tune125TWS and this is the only device that it will connect to.

      I got mine to work by down grading Bluetooth driver in device manager

      Once that was done the device displayed as Tune125TWS and I could connect without a code, hope this helps

  5. I cannot get bot buds to sync only one works. I reset them and reloaded on my Iphone and still same issue. What is the side balance they talk about and mono or stereo mode. Is that a button click or something else. About to send these back, please help.

    1. You can try to turn on the left earbud press for two seconds and then the right earbud for a couple of seconds. You will have to look at the indicator light which becomes blue on both earbuds to see if they are working together.

      The mono mode is when you are using one earbud.

      The stereo mode is when you are using both earbuds.

    1. For pin issue!! try to disconnect from the previous device and then put it back in the case. Next, take out the right one only, and go to the other device’s pair with new device option. you will be able to see the name of the earphone with a headphone sign. Now you just need to pair with it without pin. after you take out the left one, it will be automatically connected. After this process, from next time onwards you dont need to try this method anymore. you can disconnect from one device and connect with the other easily from your saved devices.

  6. I synced the button to Alexa… I would like to change it to Google but am unable to. I tried the factory reset as described above but it still brings up Alexa… help please…

  7. Like others, pin does not work to connect to PC. Will probably return for a different brand.

    0000, 1111 and 1234 do not work.

  8. I have never had so much trouble trying to use bluetooth ear buds. I got them paired once where both were working together, now they won’t, if I try to go into settings and pair the other that is not working the other goes off and the one just paired will work, but the two won’t sync. I am very close to sending them back unless I can get an answer. The print in the instructions are so small it is ridiculous. I thought I would pay a couple extra bucks and get buds from a respected name, I am having more trouble with these than the cheap ones.

  9. When pairing to an iPhone XR, it shows two TONE 125 earbuds to pair, is this correct?

    I can only get left or right to play, not both, can someone help.

  10. If you can’t pair your JBL earbuds with your PC or Android phone just put the earbuds to “pairing mode” (turn off then press the button on it and hold for a few seconds until the LED is starts blinking in white and blue) and then search for Bluetooth devices on PC or your phone to pair. You will see a new device on the list, the name will be a bit different than before (eg. JBL TUNE225TWS Stereo). Select this new device, no PIN code is required to pair.

      1. had paired with samsung s20 fan, turned off like suggested and it connected with a totally different screen on phone making it obvious it had connected…THANK YOU, I almost gave up.

  11. Do these buds can be used for phone conversations to pick up while driving? If so how do I go about it because I seem to not find instructions.

    1. Yes, they can be used for driving. When the call comes through the headset, you will press the button on the left side of the earbud to answer the call. In the event, you have difficulty to answer the call after pressing the button; you can answer the call by your pressing the answer button on your phone and it connect through the earbuds.

    1. You can call the product expert at 1-800-336-4525
      Mon – Fri: 9am – 11pm (EST)
      Sat – Sun: 9am – 5pm (EST)

  12. Seems like I am not the only one with this issue but can someone from JBL please address this issue. Pin numbers on 0000, 1111, 1234 do not work. Can attach to my phones but when I try to attach to my laptop, it doesn’t work. It only prompts for a pin number on my laptop.

  13. Pc requires Pin code to connect and displays both headbuds individualy as JBL TUNE 125WTS-LE. 0000,1111 and 1234 do not work.

  14. I have tried 0000,1111 and 1234 to pair with my CAT phone but it says cannot pair because incorrect pin or passkey??
