Klipsch T5 II Manual | Pairing & Charging Instructions 2022

Aliexpress banner

The Klipsch T5 II comes with 5mm dynamic moving coil drivers, ANC, and Transparency Modes, a battery life of around 8 hours and 32 hours using the charging case, the IPX4 sweat, and dust-proof certification, a specialized app, Bluetooth 5.0, and much more. Learn how to use them with this new Klipsch T5 II Manual.

Klipsch T5 II Manual | Everything You Need To Know!

Klipsch T5 II Manual | How to Pair / Connect?

To iOS and Android phones

Step 1: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically.

Step 2: Press and hold the multifunction touch button on both earbuds for 3 seconds. After that, a blue light will start flashing slowly, the earbuds will be ready to pair with any device.

Step 3: Go to the device’s Bluetooth settings.

Step 4: Select “Klipsch T5 ANC”. If a password is needed, type “0000”. At this moment, a blue light will start flashing in the earbuds.

Step 5: After that, a blue light will start flashing quickly, and the pairing will be done.

To PC (Windows)

Step 1: Turn on Window’s Bluetooth.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Click on Bluetooth.

Step 6: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically.

Step 7: Press and hold the multifunction touch button on both earbuds for 3 seconds. After that, a blue light will start flashing slowly, the earbuds will be ready to pair with any device.

Step 8: Select “Klipsch T5 ANC”. If a password is needed, type “0000”. At this moment, a blue light will start flashing in the earbuds.

Step 9: After that, a blue light will start flashing quickly, and the pairing will be done.

Klipsch-T5-II-Manual-1

Klipsch T5 II Manual | How to Wear?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

Klipsch T5 II Manual | How to Turn On and Off?

Turn on: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically.

Turn off: Place the earbuds into the charging case. After that, the earbuds will turn off automatically.

Klipsch-T5-II-Manual-2

How to Control? / How to Operate? – Instructions

  • Play or pause music: Press the multifunction touch button on the right earbud one time.
  • Play the next song: Press the multifunction touch button on the right earbud two times.
  • Play the previous song: Press the multifunction touch button on the right earbud three times.
  • Turn the volume up: Press the multifunction touch button on the left earbud two times.
  • Turn the volume down: Press the multifunction touch button on the left earbud three times.
  • Answer an incoming call: Press the multifunction touch button on any of the earbuds one time.
  • End a current call: Press and hold the multifunction touch button on any of the earbuds for 1 second.
  • Mute or unmute a call: Press the multifunction touch button on any of the earbuds one time during the call.
  • Switch between two calls: Press the multifunction touch button on any of the earbuds two times during the call.
  • Activate the voice assistant: Press and hold the multifunction touch button on the right earbud for 1 second.
Klipsch-T5-II-Manual-3
Credits: Pocket-lint

Klipsch T5 II Manual | How to Activate ANC and Transparency Mode?

To activate or deactivate the ANC and Transparency mode in the Klipsch T5 II, all you have to do is to press the multifunction touch button on the left earbud one time.

Klipsch T5 II Manual | How to Activate Mono Mode?

To activate or deactivate the mono mode in the Klipsch T5 II, all you have to do is to pair the earbuds to the device and take out one of the earbuds from the charging case. It will start working by itself.

Klipsch T5 II Manual | How to Charge?

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case and close the lid. The earbuds will start charging automatically.

Charging case

To charge the charging case, all you have to do is to connect the case to a USB charger or charging port with the included USB-A to C cable. It will start charging automatically.

Klipsch-T5-II-Manual-4

Klipsch T5 II Manual | How to Reset?

Step 1: Enter your device’s Bluetooth settings and forget the Klipsch T5 II.

Step 2: Press and hold the multifunction touch button on both earbuds for 15 seconds, until a red and blue light starts flashing.

Step 3: After that, the resetting will be done.

Klipsch T5 II Manual | LED Light Status

Earbuds

  • Blue light flashing slowly: Earbuds ready to pair to any device.
  • Blue light flashing quickly: Earbuds connected to any device.
  • Red light on: Earbuds charging.
  • Red light off: Earbuds fully charged.
  • Red and blue light starts flashing: Earbuds resetting.

Charging case

  • One light on: Case has 0% to 33% of battery.
  • Two lights on: Case has 33% to 66% of battery.
  • Three lights on: Case has 66% to 100% of battery.
Klipsch-T5-II-Manual-5
Credits: Pocket-lint

A Guide To Klipsch T5 II APP

The Klipsch T5 II can be used with an application, called Klipsch Connect. This application is available in the Apple Store and in the Play Store for iOS and Android devices. When opening the application, the first thing we have to do is connect our earbuds, and after that, five specific pages:

  • Principal page: This is the principal page of this application, and you will be able to see the connected device and the battery percentages of both earbuds. In addition to that, you will be able to see the five specific pages: The equalizer, the Active Noise Cancellation feature, the controls, the settings, and general information.
  • First page: On the first page of this application, you will find the equalizer settings. You can switch between different sound modes as needed or desired.
  • Second page: On the second page, there is the option to enable or disable the ANC.
  • Third page: On the third page, you will be able to configure the controls of the earbuds, and enable or disable the hands-free feature.
  • Fourth page: On the fourth page, you will find the settings of the earbuds, as well as the firmware updates.
  • Fifth page: On the fifth and last page, you will find general information about the product and the products launched by the company, as well as common problems with their answers.

Some Common Earbuds Problems & Troubleshooting

Left / Right / One side of the earbuds have stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range.

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left / Right / One side of the earbuds has low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

Microphone not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbud, so try replacing them or get a refund.

Klipsch T5 II earbuds not connecting to Windows/laptop/PC

If the earbuds are earbuds not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> elect Bluetooth,

2. Try uninstalling and reinstalling the Bluetooth driver, or update the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

Klipsch-T5-II-Manual-7
Credits: Pocket-lint

FAQs

Are Klipsch T5 II waterproof?

The Klipsch T5 II have the IPX4 certification, which means they’re dustproof, splash and sweat-resistant.

Does Klipsch T5 II have a microphone?

Yes, the Klipsch T5 II have integrated microphones.

Do Klipsch T5 II have low latency/gaming mode?

No, the Klipsch T5 II don’t have a low latency/gaming mode.

How to know when Klipsch T5 II are fully charged?

The earbuds take about 1.5 hours to charge, so after that time, they should be fully charged.

Can Klipsch T5 II connect to PC and Laptop?

Yes, the Klipsch T5 II can connect to PCs, laptops, and tablets.

We hope you now know how to operate the earphone from the above Klipsch T5 II Manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.
