Lenovo LP40 Manual | Step-by-step Guide

The Lenovo LP40 earbuds have Bluetooth 5.0, a 13mm driver, a 10-meter Bluetooth working range, a battery life of about 4 hours + 10 hours using the charging case, the IPX5 certification, and more. Learn how to use them with this new Lenovo LP40 Manual.

The Lenovo LP40 earbuds are available in the official Amazon store, and if you are interested in reading the original Lenovo manual, you can get it by clicking here.

Lenovo LP40 Specs Sheet

Model	Lenovo LP40
Dimensions	Charging case: 8.8 x 8.7 x 2.9 cm
Weight	Earbuds: 4.5 grams each Charging case: 25 grams
Waterproof/IP ratings	IPX5
Bluetooth version	V5.0
Range/Distance	10-12 meters
Connectivity Port/ Charging Cable	Type-C
Audio Decoding	AAC
Driver	13mm
Speaker frequency response	20Hz – 20kHz
Impedance	32Ω
Microphone	Silicon Microphone (MEMS Microphone)
Battery Capacity	Earbuds: 35mAh Charging case: 230mAh
Battery Life	Earbuds: 4 hours advertised Charging case: 10 hours
Charging Time	Earbuds: 1.5 hours
App Support	No
Controls/Features	Play or pause music Play the next song Play the previous song Turn the volume up Turn the volume down Answer an incoming call End a current call Reject an incoming call Voice assistant
Accessories	Charging cable Charging case User Manual
Price	Around 30 USD

Lenovo LP40 Accessories

When you buy these earbuds, they will come with some accessories, these being a charging USB type C cable for the charging case, the charging case itself, and a user manual in English and Chinese.

Lenovo LP40 Manual | Pairing & Charging Instructions

How To Pair The Earbuds?

To Android And iOS Devices

Step 1: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically and pair with each other.

If the earbuds don’t turn on automatically, then press and hold the multifunction touch button on the side of the stem on both earbuds for about 2 seconds. After that, the earbuds will turn on.

Step 2: Turn on the Bluetooth on the desired device.

Step 3: Go to the device’s Bluetooth settings.

Step 4: Select “Add device”.

Step 5: Select the Lenovo LP40 earbuds. If a password is needed, type “0000”. After that, the pairing will be done.

To Windows (PC)

Step 1: Turn on the Window’s Bluetooth.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Click on Bluetooth.

Step 6: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically and pair with each other.

If the earbuds don’t turn on automatically, then press and hold the multifunction touch button on the side of the stem on both earbuds for about 2 seconds. After that, the earbuds will turn on.

Step 7: Select the Lenovo LP40 earbuds. If a password is needed, type “0000”. After that, the pairing will be done.

How To Wear These Earbuds?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

How To Turn On And Off?

Turn on

Automatically: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically.

Manually: Press and hold the multifunction touch button on the side of the stem on both earbuds for about 2 seconds. After that, the earbuds will turn on.

Turn off

Automatically: Place the earbuds into the charging case. After that, the earbuds will turn off automatically.

Manually: Press and hold the multifunction touch button on the side of the stem on both earbuds for about 3 seconds. After that, the earbuds will turn off.

NOTE: The earbuds will turn off if they have not received a signal for 5 minutes approximately.

How to Control? / How to Operate? – Stereo Mode

• Play or pause music: Press the multifunction touch button on any of the earbuds one time.
• Play the next song: Press the multifunction touch button on the right earbud three times.
• Play the previous song: Press the multifunction touch button on the left earbud three times.
• Turn the volume up: Press the multifunction touch button on the left earbud two times.
• Turn the volume down: Press the multifunction touch button on the right earbud two times.
• Answer an incoming call: Press the multifunction touch button on any of the earbuds one time.
• End a current call: Press the multifunction touch button on any of the earbuds one time.
• Reject an incoming call: Press and hold the multifunction touch button on any of the earbuds for about 2 seconds.
• Activate the voice assistant: Press and hold the multifunction touch button on any of the earbuds for about 1.5 seconds.

How To Activate The Mono Mode?

To activate or deactivate the mono mode in the Lenovo LP40, all you have to do is pair the earbuds to the device and take out one of the earbuds from the charging case. It will start working by itself.

How to Control? / How to Operate? – Mono Mode

• Answer an incoming call: Press the multifunction touch button on the earbud one time.
• End a current call: Press the multifunction touch button on the earbud one time.
• Reject an incoming call: Press and hold the multifunction touch button on the earbud for about 2 seconds.

How To Charge The Earbuds?

Earbuds

To charge the earbuds, all you have to do is place them into the charging case. The earbuds will start charging automatically.

Charging Case

To charge the charging case, all you have to do is plug a 5V USB Type-C cable into the port on the charging case. It will start charging automatically.

What Do The Lights Mean?

Charging Case

• A red light flashing while charging: The case is charging.
• A red light on while charging: The case is fully charged.
• A green light flashing with the earbuds inside: The earbuds have a low battery.
• A green light on with the earbuds inside: The earbuds are charging.
• Said green light turns off: The earbuds are fully charged.

How To Reset And Re-Pair These Earbuds?

Step 1: Delete all “Lenovo LP40” pairing records from the connected device.

Step 2: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically.

Step 3: Press the multifunction touch button on both earbuds 6 times.

Step 4: Place the earbuds into the charging case and close its lid. After that, the resetting will be done.

Step 5: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically and pair with each other.

If the earbuds don’t turn on automatically, then press and hold the multifunction touch button on the side of the stem on both earbuds for about 2 seconds. After that, the earbuds will turn on.

Step 6: Select the Lenovo LP40 earbuds. If a password is needed, type “0000”. After that, the pairing will be done.

Some Common Problems & Troubleshooting

Left/Right/One side of the earbuds has stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left/Right/One side of the earbuds has a low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

The microphone is not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbuds, so try replacing them or getting a refund.

The earbuds are not connecting to Windows/laptop/PC

If the earbuds are earbuds not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate the pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> Select Bluetooth.

2. Try uninstalling and reinstalling the Bluetooth driver, or updating the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

FAQs

We hope you now know how to operate the earbuds from the above Lenovo LP40 Manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.
