Occiam T19 Manual | Earbuds’ Step-by-step User Guide

The Occiam T19 earbuds come with specs such as the IPX7 waterproof certification, a speaker frequency range of 20Hz to 20kHz, built-in microphones in each earbud, a total battery life of up to 90 hours using the charging case, Bluetooth 5.3, 10 meters of connection range without obstacles, SBC codec, and much more. Learn how to use these earbuds using this Occiam T19 manual!

If you are interested in purchasing these earbuds, you can easily do it using the Amazon online store. Also, in case you are interested in giving the original manual a look, you can do it here.

Occiam T19 Specs Sheet

ModelOcciam T19
WeightEarbuds and charging case: Around 80 grams
Waterproof/IP ratings  IPX7
Bluetooth version          V5.3
Range/Distance10 meters
Connectivity Port/Charging CableType-C
Audio Decoding               SBC
Speaker frequency response20Hz – 20kHz
Battery Life       Earbuds: About 8 hours
Charging case: About 82 hours
Charging Time  Earbuds: Around 1.5 hours
Charging case: About 2 hours
App Support     No
Controls/Features         Play and pause a song, play the next and previous song, answer, end, and reject a call, turn the volume up and down, voice assistant
Accessories       Charging case, USB cable, user manual, ear tips
PriceAround 50 USD

Occiam T19 Accessories

The earbuds come with the following accessories:

  • Charging case.
  • USB cable.
  • User manual.
  • Ear tips.
Occiam-T19-Manual-1

Occiam T19 Manual | Guide & Troubleshooting

How To Pair The Earbuds?

To Android And iOS Devices

Step 1: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically and pair with each other.

A blue light will start flashing quickly in one of the earbuds and slowly on the other one, and the earbuds will now be ready to pair with any device.

Step 2: Unlock the desired device.

Step 3: Go to the device’s settings.

Step 4: Turn on Bluetooth on the desired device.

Step 5: Search for a new device.

Step 6: Select the T19 earbuds. If a password is needed, type “0000” or “1234”.

After that, the pairing will be done.

To Windows (PC)

Step 1: Turn on the Window’s Bluetooth.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Click on Bluetooth.

Step 6: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically and pair with each other.

A blue light will start flashing quickly in one of the earbuds and slowly on the other one, and the earbuds will now be ready to pair with any device.

Step 7: Select the T19 earbuds. If a password is needed, type “0000” or “1234”.

After that, the pairing will be done.

How To Wear These Earbuds?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

How To Turn On And Off?

Turn On

Automatically: Open the lid of the charging case and take the earbuds out. After that, the earbuds will turn on automatically.

Manually: Press and hold the multifunction touch button on both earbuds for about 2 seconds. After that, the earbuds will turn on.

Turn Off

Automatically: Place the earbuds into the charging case. After that, the earbuds will turn off automatically.

Manually: Press and hold the multifunction touch button on both earbuds for about 5 seconds. After that, the earbuds will turn off.

Occiam-T19-Manual-3

How To Control These Earbuds?

NOTE: The multifunction touch button is placed on the top part of the body of the earbuds.

  • Play or pause a song: Press the multifunction touch button on any of the earbuds one time.
  • Play the next song: While listening to music, press the multifunction touch button on the right earbud two times.
  • Play the previous song: While listening to music, press the multifunction touch button on the left earbud two times.
  • Turn the volume up: Press and hold the multifunction touch button on the right earbud.
  • Turn the volume down: Press and hold the multifunction touch button on the left earbud.
  • Answer an incoming call: Press the multifunction touch button on any of the earbuds one time.
  • End a current call: Press the multifunction touch button on any of the earbuds one time.
  • Reject an incoming call: Press and hold the multifunction touch button on any of the earbuds for about 2 seconds.
  • Activate the voice assistant: Press the multifunction touch button on any of the earbuds three times.

How To Reset And Re-Pair These Earbuds?

Step 1: Delete the T19 earbuds from the devices’ Bluetooth list.

Step 2: Turn off Bluetooth on the device.

Step 3: Take both earbuds out of the case.

Step 4: Press and hold the multifunction touch button on both earbuds for about 2 seconds. They will turn off.

Step 5: Press and hold the multifunction touch button on both earbuds for about 5 seconds. They will turn on.

Make sure they do not connect to any devices at this time.

Step 6: Press the multifunction touch button on both earbuds five times, and a blue light will flash three times.

This will reset the earbuds, and they will turn off.

Step 7: Turn on Bluetooth on the desired device.

Step 8: Search for a new device.

Step 9: Press and hold the multifunction touch button on both earbuds for about 2 seconds. After that, the earbuds will turn on.

A blue light will start flashing quickly in one of the earbuds and slowly on the other one, and the earbuds will now be ready to pair with any device.

Step 10: Select the T19 earbuds. If a password is needed, type “0000” or “1234”.

After that, the pairing will be done.

NOTE: If it shows “Unsuccessfully connected,” please unpair or delete all the T19 records on the device and then search for T19 to connect again.

How To Charge The Earbuds?

Earbuds

To charge the earbuds, all you have to do is place them into the charging case. The earbuds will start charging automatically.

Charging Case

To charge the charging case, all you have to do is connect the case to a USB charger or charging port. It will start charging automatically.

What Do The Lights Mean?

Earbuds

  • A blue light will flashes quickly in one of the earbuds and slowly on the other one: The earbuds will now be ready to pair with any device
  • A blue light flashes three times while resetting: The earbuds are resetting.

Charging Case

  • 0 to 99 appears on the display while charging: The case is charging.
  • A 100 appears on the display while charging: The case is fully charged.
  • Flashing down and up design with the earbuds inside: The earbuds are charging.
  • No flashing design with the earbuds inside: The earbuds are fully charged.

Do These Earbuds Have An App?

Sadly, these earbuds don’t come with app support.

Some Common Problems & Troubleshooting

Left/Right/One side of the earbuds has stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range.

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left/Right/One side of the earbuds has a low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

The microphone is not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbuds, so try replacing them or getting a refund.

The earbuds are not connecting to Windows/laptop/PC

If the earbuds are not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate the pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> Select Bluetooth.

2. Try uninstalling and reinstalling the Bluetooth driver, or updating the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

Occiam-T19-Manual-7

FAQs

Are the Occiam T19 waterproof?

Yes, these earbuds are waterproof (IPX6 and up). They have a rating of IPX7, meaning that they not only are against water but are also protected against the effects of immersion.

Do the Occiam T19 have a microphone?

Yes, the earbuds come with integrated microphones.

Do the Occiam T19 have a low latency/gaming mode?

No, these earbuds don’t have a low latency/gaming mode.

Can the Occiam T19 connect to PCs and laptops?

Yes, these earbuds can connect to PCs and laptops.

Are the Occiam T19 noise-canceling?

No, these earbuds don’t come with noise-cancellation technology.

How to know when the Occiam T19 are fully charged?

When the earbuds are charging, some lights flash on the charging case. When fully charged, the lights turn off.

We hope you now know how to operate the earbuds from the above Occiam T19 manual. Want to know anything about the earphones? Do not hesitate to ask in the comment section below.
