A while ago, we talked to you about the manual of one of the most popular wireless headphones launched by the Raycon brand, the Raycon E55, and today we are going to show you the user manual of another of their headphones, and it is about of the Raycon E70. Stay with us to learn how to use these wireless headphones with this new Raycon E70 Earbuds Manual!

Raycon E70 Earbuds Manual | All You Need To Know!

Raycon E70 Earbuds Manual – How to pair or connect?

  • Step 1: Open the upper cover of the charging case and press and hold the multifunction button on any of the earbuds for 3 seconds. The earbuds will automatically enter the Bluetooth pairing mode, and the buds’ indicator lights will flash red and blue alternately.
  • Step 2: Turn on the Bluetooth function in the Bluetooth device.
  • Step 3: Refresh the Bluetooth device listing.
  • Step 4: Select the paired audio device named “RAYCON RBE770” to connect. After this, the indicator lights on the earbuds will go off after a successful pairing.

Raycon E70 Earbuds Manual – How to charge?

Charging the earbuds

To charge the earbuds, all you have to do is put the buds in place in the charging case, and they will start charging automatically.

aliexpress ad banner 300 x 250

Charging the charging case

To charge the charging case, all you have to do is to plug one end of the USB cable into a 5V power supply, and the other end into the charging port on the charging case. After doing this, the indicator lights will flash during the charging process and then turn off.

Raycon E70 Earbuds Manual – How Long to Charge?

About charging times, the Raycon E70 takes between 1 hour to be fully charged. The charging case, on the other hand, takes 1 hour to fully charge.

Raycon E70 Earbuds Manual – LED light status

  • Charging the earbuds: The LED lights on the earbuds flash.
  • Charging the charging case: The LED lights on the charging case flash.
  • Earbuds fully charged: The LED lights on the earbuds turn off.
  • Charging case fully charged: The LED lights on the charging case long gleams.
Raycon E70 Manual - LED light status

Raycon E70 Earbuds Manual – Controls Instruction

  • Play / pause music: Double-tap the multifunction button on any of the earbuds.
  • Play the next song: Triple-tap the multifunction button on the right earbud.
  • Play the previous song: Triple-tap the multifunction button on the left earbud.
  • Volume +: Triple-tap the multifunction button on the right earbud.
  • Volume -: Triple-tap the multifunction button on the left earbud.
  • Activate voice assistant: Tap the multifunction button on any of the earbuds 4 times.
  • Activate equalizer mode: Press and hold the multifunction button on the left earbud for 1.5 seconds.
  • Activate awareness & ANC mode: Press and hold the multifunction button on the right earbud for 1.5 seconds.
  • Power on the earbuds: Press and hold the multifunction button on any of the earbuds for 3 seconds.
  • Power off the earbuds: Press and hold the multifunction button on any of the earbuds for 10 seconds.

Raycon E70 Earbuds Manual – How to connect to PC?

  • Step 1: Disconnect the currently connected Bluetooth device, and then the earbuds will automatically enter the Bluetooth pairing mode.
  • Step 2: Put the left and right earbuds back into the charging case and keep the case open.
  • Step 3: Pair the earbuds as explained in “How to pair or connect?”.

Raycon E70 Earbuds Manual – How to Reset?

  • Step 1: Delete the “RAYCON RBE770” from the Bluetooth settings on your device.
  • Step 2: In the off state, press and hold the multifunction button on both earbuds for 8 seconds, until the red and blue lights alternately flash.
  • Step 3: Wait for 3-5 seconds, so that the red and blue light of the right earbud flash alternately, and the light of the left earbud goes out.
  • Step 4: Close the charging case, the reset is now successfully completed, so remove them from the charging case re-pair them to any device you want.
How to Reset? Raycon E70 Earbuds manual

Q&A

Are the Raycon E70 waterproof?

Yes, the Raycon E70 are waterproof thanks to their IPX7 water-resistant grade.

Does the Raycon E70 have a microphone?

Yes, the Raycon E70 have a built-in microphone.

Raycon E70 Earbuds Manual – Warnings

  1. Never dismantle or refit the product to avoid malfunction or fire hazards.
  2. Keep away from corrosive liquids to avoid damages to the product.
  3. Keep away from extreme ambient temperatures below -10C° or above 60°C.
  4. Keep away from children and pets.
  5. Never touch the earbuds with sharp objects, otherwise, it will easily cause scratches.
  6. Don’t use the product in thunderstorm weather to avoid malfunction or electric shock.
  7. If it has not been used for more than a month, please charge and maintain it in time to ensure that it is safe.

We hope you now know how to operate the earphone from the above Raycon E70 Manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.
