Skullcandy Burton Mod Manual | Step-by-step Pairing

The Skullcandy Burton Mod earbuds come with specs such as app support, a total battery life of up to 34 hours using the charging case, multipoint pairing, Stay-Aware mode, Bluetooth 5.2, 6mm drivers, built-in microphones with Clear Voice Smart technology, the IPX5 sweat and dust-proof certification, and much more. Learn how to use these earbuds using this manual!

Skullcandy Burton Mod Manual | All You Have To Know

How To Wear These Earbuds?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

How To Turn On And Off?

Turn On

Automatically: Open the lid of the charging case and take the earbuds out. After that, they will turn on automatically.

Manually: Press and hold the multifunction touch area on both earbuds for about 1 second.

Turn Off

Automatically: Place the earbuds into the charging case. After that, the earbuds will turn off automatically.

Manually: Press the multifunction touch area on both earbuds two times, and then press and hold for about 1 second.

How To Pair The Earbuds?

To Android Or iOS Devices

Step 1: Remove the stickers covering the charging points on both earbuds and place them into the charging case. Make sure that there is a red light on the earbuds, meaning that they are charging.

Step 2: Open the lid of the charging case and take the earbuds out. After that, they will turn on automatically. If they don’t turn on, then press and hold the multifunction touch area on both earbuds for about 1 second.

When a red and blue light starts flashing on the earbuds, and the “Ready to pair” voice prompt is heard, the earbuds will be ready to pair with any device.

NOTE: If the earbuds don’t enter pairing mode automatically, then press the multifunction touch button on both earbuds one time, and then press and hold for about 1 second, until a red and blue light starts flashing on the earbuds, and the “Ready to pair” voice prompt is heard. This will activate the manual pairing mode.

Step 3: Unlock the desired device.

Step 4: Go to the device’s settings.

Step 5: Turn on Bluetooth on the desired device.

Step 6: Search for a new device.

Step 7: Select the Mod earbuds. If a password is needed, type “0000”. After that, the “Connected” voice prompt will sound, and the pairing will be done.

To Windows (PC)

Step 1: Turn on Window’s Bluetooth.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Click on Bluetooth.

Step 6: Remove the stickers covering the charging points on both earbuds and place them into the charging case. Make sure that there is a red light on the earbuds, meaning that they are charging.

Step 7: Open the lid of the charging case and take the earbuds out. After that, they will turn on automatically. If they don’t turn on, then press and hold the multifunction touch area on both earbuds for about 1 second.

When a red and blue light starts flashing on the earbuds, and the “Ready to pair” voice prompt is heard, the earbuds will be ready to pair with any device.

NOTE: If the earbuds don’t enter pairing mode automatically, then press the multifunction touch button on both earbuds one time, and then press and hold for about 1 second, until a red and blue light starts flashing on the earbuds, and the “Ready to pair” voice prompt is heard. This will activate the manual pairing mode.

Step 8: Select the Mod earbuds. If a password is needed, type “0000”. After that, the “Connected” voice prompt will sound, and the pairing will be done.

How To Re-Sync The Earbuds?

If there is missing audio in one of the earbuds, then re-sync them. To do this, all you have to do is to place them into the charging case and make sure that there is a red light on the earbuds, meaning that they are charging; when removed, both earbuds should play audio.

With that being said, if that doesn’t happen, then do the following steps:

Step 1: Place the earbuds into the charging case and keep the lid open.

Step 2: Go to the device’s settings and turn off Bluetooth.

Step 3: Take both earbuds out of the charging case and make sure they are powered on.

Step 4: Press the multifunction touch area on both earbuds 3 times. The light on the earbuds will start flashing red and blue as the earbuds re-sync.

After that, a blue light will flash 4 times, indicating that the process was successful.

Step 5: Go to the device’s settings and turn on Bluetooth.

Step 6: Select the Mod earbuds.

A blue light will flash 1 time, and a voice prompt will indicate when the earbuds have reconnected to the device.

Multipoint Pairing: Pair To A Second Device

To use the multipoint pairing and pair to a 2nd device when you’re already powered on and connected to a device, all you have to do is to is following the next steps:

Step 1: Press the multifunction touch area on both earbuds one time.

Step 2: Press and hold the multifunction touch area on both earbuds for about 3 seconds. This will make both earbuds enter pairing mode again, the “Ready to pair” voice prompt will sound, and a red and blue light starts flashing on the earbuds.

Step 3: Unlock the second device.

Step 4: Go to the device’s settings.

Step 5: Turn on Bluetooth.

Step 6: Search for a new device.

Step 7: Select the Mod earbuds. If a password is needed, type “0000”. After that, the “Connected” voice prompt will sound, and the pairing will be done.

Once paired to the 2nd device, you will be able to seamlessly stream from either device as needed.

NOTE: Now that you’ve paired to multiple devices, each time you power on your earbuds, they will automatically sync to the 2 most recently paired devices.

How To Control These Earbuds? – Stereo Mode

• Play or pause a song: Press the multifunction touch area on any of the earbuds one time.

• Turn the volume up: Press the multifunction touch area on the right earbud two times.
• Turn the volume down: Press the multifunction touch area on the left earbud two times.
• Play the next song: Press and hold the multifunction touch area on the right earbud for about 1 second.
• Play the previous song: Press and hold the multifunction touch area on the left earbud for about 1 second.
• Answer an incoming call: Press the multifunction touch area on any of the earbuds one time.
• End a current call: Press the multifunction touch area on any of the earbuds one time.

How To Activate The Mono Mode?

To activate or deactivate the mono mode in these earbuds, all you have to do is to pair the earbuds to the device and take out one of the earbuds from the charging case. It will start working by itself.

How To Charge The Earbuds?

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case. The earbuds will start charging automatically.

Charging Case

To charge the charging case, all you have to do is to connect the case to a USB charger or charging port. It will start charging automatically.

How To Reset These Earbuds?

If the earbuds don’t have audio streaming as they should, or they are having pairing issues, please proceed to fully reset the earbuds with the following steps:

Step 1: Delete all the pairing information from the earbuds on the connected device.

Step 2: Turn the device’s Bluetooth off.

Step 3: Remove both earbuds from the charging case, and a tone and voice prompt will indicate that the earbuds are powered on.

Step 4: Press and hold the multifunction touch area on both earbuds for about 3 seconds. A tone will indicate a successful reset and a red light will flash 2 times, followed by a blue light flashing 2 more times.

This means that the earbuds are back in pairing mode.

Step 5: Go to the device’s settings.

Step 6: Turn on Bluetooth on the desired device.

Step 7: Search for a new device.

Step 8: Select the Mod earbuds. If a password is needed, type “0000”. After that, the “Connected” voice prompt will sound, and the pairing will be done.

The Earbuds’ Voice Prompts

• Ready to pair: The earbuds are ready to pair with any device.
• Connected: The earbuds are connected to the device.
• Battery low: The earbuds have a low battery level (about 15% and 8% of battery).

What Does The Lights Mean?

Earbuds

• A red and blue light flashing: The earbuds will be ready to pair with any device.
• A red light on while on the charging case: The earbuds are charging.
• A blue light on while on the charging case: The earbuds are fully charged.
• A red and blue light flashing: The earbuds are re-syncing.
• A blue light flashes 4 times: The re-syncing process is done.
• A blue light flashes 1 time: The earbuds have reconnected to the device.
• A red light flashes 2 times: The earbuds are resetting.
• A blue light flashes 2 times: The earbuds are resetting.

Charging Case

• A white light flashing above the charging port: The case is charging.
• A white light on above the charging port: The case is fully charged.
• A red light flashing: The case has between 0% and 40% of battery.
• A yellow light flashing: The case has between 40% and 95% of battery.
• A green light flashing: The case has between 95% and 100% of battery.

A Guide to The Skullcandy Burton Mod APP

The Skullcandy Burton Mod earbuds can be used with an app, called Skullcandy App. This app is available in the Apple Store and in the Play Store for iOS and Android devices. When opening the app, the first thing we have to do is connect our earbuds, and after that, some options will appear:

Not only will you be able to see the battery percentage of the earbuds, as well as their status and firmware version, but there is also a configuration options section. When you download the app, you will be able to configure the volume of the earbuds manually, in addition to being able to change the equalizer to its four versions (Music, Podcast, Movie, and Custom), change the hearing modes (Stay-Aware on and off), and special options such as configuring the button settings, multipoint pairing, and a user guide.

How To Update The Earbuds’ Firmware?

Occasionally, you’ll receive notifications through the Skullcandy App that your product is ready for a firmware update. FOTA (Firmware Over-The-Air) updates will be prompted on the home page of the specialized app on the connected device.

Step 1: Open the Skullcandy App.

Step 2: Press the “Update” button on the home page for more detailed information before getting started with your upgrade.

Step 3: After reviewing the firmware improvements and or feature upgrades, swipe forward and get ready to begin the update.

NOTE: The entire process could take about 5 to 10 minutes, and the earbuds will need to have a battery capacity of over 25% to begin.

Step 4: Press the “Start the update” button. After that, be sure to maintain a constant WiFi or phone service, keep the earbuds and connected device powered on and close together to maintain the Bluetooth connection, and do not exit the Skullcandy App (this can update in the background, but the app must continue running).

Once the update process has finished, you will be notified that the firmware update was successfully completed.

Some Common Problems & Troubleshooting

Left/Right/One side of the earbuds has stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left/Right/One side of the earbuds has a low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

The microphone is not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbud, so try replacing them or get a refund.

The earbuds are not connecting to Windows/laptop/PC

If the earbuds are earbuds not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate the pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> select Bluetooth.

2. Try uninstalling and reinstalling the Bluetooth driver, or updating the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

FAQs

We hope you now know how to operate the earphone from the above Skullcandy Burton Mod manual! Want to know anything about the earphones? Do not hesitate to ask in the comments section.
