The SoundPEATS TrueCapsule comes with Bluetooth 5.0 with HSP1.2, HFP1.6, A2DP1.3, and AVRCP1.6 profiles, the IPX5 certification, battery life of 4 hours, and much more. Learn how to use them with this new SoundPEATS TrueCapsule Manual.

SoundPEATS TrueCapsule Manual | Everything You Need To Know!

SoundPEATS TrueCapsule Manual | How to Pair / Connect?

To iOS and Android phones

Step 1: Take both earbuds out of the charging case. The earbuds will automatically turn on and a white light will turn on for 1 second.

After that, the earbuds will pair to each other and the light on the left earbud will turn off and a red and white light will flash alternately or solid white light on the right earbud. After this, they will be ready to pair to any device.

Step 2: Go to the Bluetooth settings.

Step 3: Select “SoundPEATS TrueCapsule”. If a password is needed, type “0000”.

Step 4: After that, a red light on the right earbud will turn on and the pairing will be done.

To PC (Windows)

Step 1: Turn on Window’s Bluetooth.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Click on Bluetooth.

Step 6: Take both earbuds out of the charging case. The earbuds will automatically turn on and a white light will turn on for 1 second.

After that, the earbuds will pair to each other and the light on the left earbud will turn off and a red and white light will flash alternately or solid white light on the right earbud. After this, they will be ready to pair to any device.

Step 7: Select “SoundPEATS TrueCapsule”. If a password is needed, type “0000”.

Step 8: After that, a red light on the right earbud will turn on and the pairing will be done.

SoundPEATS-TrueCapsule-Manual-1

SoundPEATS TrueCapsule Manual | How to Wear?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit.

SoundPEATS-TrueCapsule-Manual-2

SoundPEATS TrueCapsule Manual | How to Turn On and Off?

Turn on

Automatically: Take both earbuds out of the charging case. They will turn on automatically and a white light will flash for 1 second.

Manually: Press and hold the multifunction touch button on both earbuds for 1.5 seconds. The earbuds will turn on and a white light will flash for 1 second.

Turn off

Automatically: Place the earbuds into the charging case. They will turn off automatically and a red light will flash for 1 second.

Manually: Press and hold the multifunction touch button on both earbuds for 8 seconds. The earbuds will turn off and a red light will flash for 1 second.

SoundPEATS-TrueCapsule-Manual-3

SoundPEATS TrueCapsule Manual | How to Activate Mono Mode?

To activate the mono mode in the SoundPEATS TrueCapsule, all you have to do is to pick up one of the earbuds from the charging case, and it will work by itself.

How to Control? / How to Operate? – Instructions

  • Play and pause music: Press the multifunction touch button on the right earbud two times.
  • Play the next song: Press and hold the multifunction touch button on the right earbud for 1.5 seconds.
  • Play the previous song: Press and hold the multifunction touch button on the left earbud for 1.5 seconds.
  • Answer an incoming call: Press the multifunction touch button on the right earbud two times.
  • End a call: Press the multifunction touch button on the right earbud two times.
  • Reject an incoming call: Press and hold the multifunction touch button on the right earbud for 1.5 seconds.
  • Switch between two active calls: Press and hold the multifunction button on the right earbud for 2 seconds.
  • Activate the Voice Assistant: Press the multifunction touch button on the left earbud two times.
SoundPEATS-TrueCapsule-Manual-4

SoundPEATS TrueCapsule Manual | How to Charge

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case and close the lid. The earbuds will start charging automatically.

Charging case

To charge the charging case, all you have to do is plug a 5V USB Type-C cable into the port on the charging case. It will start charging automatically.

SoundPEATS-TrueCapsule-Manual-5

SoundPEATS TrueCapsule Manual | LED Light Status

Earbuds

  • White light flashing for 1 second: Earbuds turn on.
  • Red light flashing for 1 second: Earbuds turn off.
  • Light on the left earbud turns off and red and white light flashing alternately or solid white light on the right earbud: Earbuds connected to each other.
  • Red and white light flashing alternately on the right earbud: Earbuds ready to pair to any device.
  • Red light on right earbud: Earbud paired to device.
  • Red light on: Earbuds charging.
  • Red light off: Earbuds fully charged.
  • White light flashes twice: Earbuds resetting.
SoundPEATS-TrueCapsule-Manual-6

Charging case

  • Four white lights on: 75 – 100% of battery level.
  • Three white lights on: 50 – 74% of battery level.
  • Two white lights on: 25 – 49% of battery level.
  • One white light on: 10 – 24% of battery level.
  • One white light flashing: Less than 10% of battery.
  • One white light flashing while charging: 10 – 24% of battery level.
  • One white light on and one flashing while charging: 25 – 49% of battery level.
  • Two white lights on one flashing while charging: 50 – 74% of battery level.
  • Three white lights on one flashing while charging: 75 – 100% of battery level.
  • Four white lights on white charging: Case fully charged.
SoundPEATS-TrueCapsule-Manual-7

SoundPEATS TrueCapsule Manual | How to Reset?

Step 1: Disconnect the earbuds from the connected device.

Step 2: Place the earbuds into the charging case and keep the lid open.

Step 3: Press and hold the multifunction touch button on both earbuds for 10 seconds, until a white light on the earbuds flashes twice.

Step 4: After that, the resetting will be done.

SoundPEATS-TrueCapsule-Manual-8
Credits: MegaBites

Some Common Earbuds Problems & Troubleshooting

Left / Right / One side of the earbuds have stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range.

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left / Right / One side of the earbuds has low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

Microphone not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbud, so try replacing them or get a refund.

SoundPEATS TrueCapsule earbuds not connecting to Windows/laptop/PC

If the earbuds are earbuds not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> elect Bluetooth,

2. Try uninstalling and reinstalling the Bluetooth driver, or update the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

SoundPEATS-TrueCapsule-Manual-9

FAQs

Are SoundPEATS TrueCapsule waterproof?

The SoundPEATS TrueCapsule have the IPX5 certification, which means they’re dustproof and protected against water projected from a nozzle.

Does SoundPEATS TrueCapsule have a microphone?

Yes, the SoundPEATS TrueCapsule have integrated microphones.

Do SoundPEATS TrueCapsule have low latency/gaming mode?

No, the SoundPEATS TrueCapsule don’t have low latency/gaming mode.

How to know when SoundPEATS TrueCapsule are fully charged?

When the earbuds are charging, a red light will turn on in the earbuds. When fully charged, that light will turn off.

Can SoundPEATS TrueCapsule connect to PC and Laptop?

Yes, the SoundPEATS TrueCapsule can connect to PCs, laptops and tablets.

We hope you now know how to operate the earphone from the above SoundPEATS TrueCapsule Manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.

In case you want or need to contact the SoundPEATS company, all your information can be found on its Contact Us page, where you can find numbers and emails available for several countries! Also, they have a Support page, with FAQs and information about their products!
