TaoTronics SoundLiberty 77 Manual | Step-by-step Guide 2021

Aliexpress banner

The TaoTronics SoundLiberty 77 comes with Bluetooth 5.0 with HSP1.2, HFP1.6, and A2DP1.3 profiles, the IPX7 certification, battery life of 5 hours, and much more. Learn how to use them with this new TaoTronics SoundLiberty 77 Manual.

TaoTronics SoundLiberty 77 Manual | Everything You Need To Know!

TaoTronics SoundLiberty 77 Manual | How to Pair / Connect?

To iOS and Android phones

Step 1: Open the lid of the charging case. The earbuds will automatically turn on and pair to each other. When a blue and white light starts flashing alternately on both earbuds, they will be ready to pair.

Step 2: Go to the Bluetooth settings.

Step 3: Select “TaoTronics SoundLiberty 77”. If a password is needed, type “0000”.

Step 4: After that, a blue light will flash slowly on both earbuds and the pairing will be done.

To PC (Windows)

Step 1: Turn on Window’s Bluetooth.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Click on Bluetooth.

Step 6: Open the lid of the charging case. The earbuds will automatically turn on and pair to each other. When a blue and white light starts flashing alternately on both earbuds, they will be ready to pair.

Step 7: Select “TaoTronics SoundLiberty 77”. If a password is needed, type “0000”.

Step 8: After that, a blue light will flash slowly on both earbuds and the pairing will be done.

TaoTronics-SoundLiberty-77-Manual-1
Credits: Headphones Addict

TaoTronics SoundLiberty 77 Manual | How to Wear?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit.

TaoTronics-SoundLiberty-77-Manual-9

TaoTronics SoundLiberty 77 Manual | How to Turn On and Off?

Turn on: Open the lid of the charging case. They will turn on automatically.

TaoTronics-SoundLiberty-77-Manual-3

Turn off: Place the earbuds into the charging case and close its lid. They will turn off automatically.

TaoTronics-SoundLiberty-77-Manual-4

How to Control? / How to Operate? – Instructions

  • Play or pause music: Press the multifunction touch button on any of the earbuds two times.
  • Turn the volume up: Press the multifunction touch button on the right earbud once.
  • Turn the volume down: Press the multifunction touch button on the left earbud once.
  • Play the next song: Press the multifunction touch button on any of the earbuds three times.
  • Play the previous song: Press the multifunction touch button on any of the earbuds three times.
  • Answer an incoming call: Press the multifunction touch button on any of the earbuds once.
  • End a call: Press the multifunction touch button on any of the earbuds two times.
  • Reject an incoming call: Press and hold the multifunction touch button on any of the earbuds for 2 seconds.
  • Redial: Press the multifunction touch button on any of the earbuds three times in a non-music playing state.
  • Turn on/off voice control: When paired successfully, press and hold the multifunction button on any of the earbuds for 2 seconds, until a beep is heard.
TaoTronics-SoundLiberty-77-Manual-5

TaoTronics SoundLiberty 77 Manual | How to Activate Mono Mode?

To activate the mono mode in the TaoTronics SoundLiberty 77, all you have to do is to pick up one of the earbuds from the charging case, and it will work by itself.

TaoTronics SoundLiberty 77 Manual | How to Charge

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case and close the lid. The earbuds will start charging automatically.

Charging case

To charge the charging case, all you have to do is plug a 5V USB Type-C cable into the port on the charging case. It will start charging automatically.

TaoTronics-SoundLiberty-77-Manual-6

TaoTronics SoundLiberty 77 Manual | How to Reset?

Step 1: Place the earbuds into the charging case and close the lid.

Step 2: Open the lid of the charging case.

Step 3: With the earbuds still inside, press and hold the multifunction touch button on both earbuds for about 10 seconds, until a white light flashes three times on the right earbud.

Step 4: After that, the resetting will be done.

TaoTronics SoundLiberty 77 Manual | LED Light Status

Earbuds

  • Blue and white light flashing alternately on both earbuds: Earbuds ready to pair to any device.
  • Blue light flashing slowly on both earbuds: Pairing successful.
  • White light flashing three times on the right earbud: Earbuds resetting.

Charging case

The four charging indicators will light up progressively white charging.

TaoTronics-SoundLiberty-77-Manual-7
Credits: Headphones Addict

Some Common Earbuds Problems & Troubleshooting

Left / Right / One side of the earbuds have stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range.

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left / Right / One side of the earbuds has low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

Microphone not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbud, so try replacing them or get a refund.

TaoTronics SoundLiberty 77 earbuds not connecting to Windows/laptop/PC

If the earbuds are earbuds not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> elect Bluetooth,

2. Try uninstalling and reinstalling the Bluetooth driver, or update the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

TaoTronics-SoundLiberty-77-Manual-8
Credits: Scarbir

FAQs

Are TaoTronics SoundLiberty 77 waterproof?

The TaoTronics SoundLiberty 77 have an IPX7 water-resistant rating, meaning that they not only are they against water but they are also protected against the effects of immersion.

Does TaoTronics SoundLiberty 77 have a microphone?

Yes, the TaoTronics SoundLiberty 77 have integrated microphones.

Do TaoTronics SoundLiberty 77 have low latency/gaming mode?

No, the TaoTronics SoundLiberty 77 don’t have low latency/gaming mode.

How to know when TaoTronics SoundLiberty 77 are fully charged?

The earbuds take about 2 hours to charge so, after that time, they should be fully charged.

Can TaoTronics SoundLiberty 77 connect to PC and Laptop?

Yes, the TaoTronics SoundLiberty 77 can connect to PCs, laptops and tablets.

We hope you now know how to operate the earphone from the above TaoTronics SoundLiberty 77 Manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.

In case you want or need to contact the TaoTronics company, all your information can be found on its Contact Us page, where you can find numbers and emails available for several countries! Also, they have a Support page, with FAQs and information about their products!
