The Technics EAH-AZ60 earbuds come with app support, Bluetooth 5.2 with 10 meters of working range, support for the A2DP, AVRCP, HSP, HFP codecs, Ambient Sound mode, the IPX4 sweat and dust-proof certification, and much more. Learn how to use these earbuds using this Technics EAH-AZ60 manual!

If you are interested in purchasing these earbuds, you can easily do it using the AliExpress official website. Also, if you want to give the original manual a look, you can do it here.

Technics EAH-AZ60 Specs Sheet

Model	Technics EAH-AZ60
Weight	Earbuds: 7 grams each Charging case: 52 grams
Waterproof/IP ratings	IPX4
Bluetooth version	V5.2
Range/Distance	10 meters
Driver	8mm
Audio Decoding	SBC, AAC
Connectivity Port/Charging Cable	Type-C
Speaker frequency response	20Hz – 20kHz
Battery Life	Earbuds: About 7 hours (ANC on)/7.5 hours (ANC off) Charging case: About 24 hours (ANC on)/25 hours (ANC off)
Charging Time	Earbuds: About 1 hour Charging case: About 2 hours
App Support	Yes, Technics Audio Connect
Controls/Features	Play or pause music, turn the volume up and down, answer, end, and reject a call, voice assistant, mute or unmute the microphone, switch the noise level heard from the other party, ANC, Ambient mode
Accessories	Charging case, user manual, USB cable, ear tips, warranty card
Price	About 240 USD

Technics EAH-AZ60 Accessories

The earbuds come with the following accessories:

• Charging case.
• User manual.
• USB cable.
• Ear tips.
• Warranty card.

Technics EAH-AZ60 | Pairing & Charging Guide

How to Pair The Earbuds?

To iOS and Android Phones

Step 1: Open the lid of the charging case and take the earbuds out. After that, a blue light will flash, and the earbuds will turn on automatically.

When a blue and red light starts flashing on the earbuds, it means that they will be ready to pair with any device.

Step 2: Turn on Bluetooth on the desired device.

Step 3: Go to the device’s Bluetooth settings.

Step 4: Select “EAH-AZ60”. If a password is needed, type “0000”.  After that, a blue light will flash on the earbuds every 5 seconds, and the pairing will be done.

To PC (Windows)

Step 1: Turn on Bluetooth on the desired device.

Step 2: Go to the settings.

Step 3: Go to “Bluetooth and other devices”.

Step 4: Click on “Add device”.

Step 5: Open the lid of the charging case and take the earbuds out. After that, a blue light will flash, and the earbuds will turn on automatically.

When a blue and red light starts flashing on the earbuds, it means that they will be ready to pair with any device.

Step 6: Select “EAH-AZ60”. If a password is needed, type “0000”.  After that, a blue light will flash on the earbuds every 5 seconds, and the pairing will be done.

How to Pair To A Second Device?

Step 1: Place both earbuds into the charging case for about 10 seconds.

Step 2: Take them out of the charging case, until a blue light starts flashing on the earbuds.

Step 3: Press and hold the multifunction touch sensor on both earbuds for about 7 to 10 seconds, until a blue and red light starts flashing.

Step 4: Turn on Bluetooth on the desired device.

Step 5: Go to the device’s Bluetooth settings.

Step 6: Select “EAH-AZ60”. If a password is needed, type “0000”.  After that, a blue light will flash on the earbuds every 5 seconds, and the pairing will be done.

How to Wear?

Step 1: Take both earbuds out of the charging case.

Step 2: Identify the left and right earbuds.

Step 3: Choose the ear tips that best suit your ears.

Step 4: Insert the headphones into the inner canal of the ears.

Step 5: Rotate for the best possible comfort and best fit, and make sure that the microphone is pointing to the mouth.

How to Turn On and Off?

Turn on: Open the lid of the charging case and take the earbuds out. After that, a blue light will flash, and the earbuds will turn on automatically.

Turn off: Place the earbuds into the charging case. After that, the earbuds will turn off automatically.

How to Control? / How to Operate? – Instructions

NOTE: The multifunction touch button is placed on the top part of the body of the earbuds.

• Play or pause music: Press the multifunction touch sensor on any of the earbuds one time.
• Play the next song: Press the multifunction touch sensor on the right earbud two times.
• Play the previous song: Press the multifunction touch sensor on the right earbud three times.
• Turn the volume up: Press the multifunction touch sensor on the left earbud three times.
• Turn the volume down: Press the multifunction touch sensor on the left earbud two times.
• Answer an incoming call: Press the multifunction touch sensor on any of the earbuds one time.
• End a current call: Press and hold the multifunction touch sensor on any of the earbuds for about 2 seconds.
• Reject an incoming call: Press and hold the multifunction touch sensor on any of the earbuds for about 2 seconds.
• Mute or unmute the microphone: Press the multifunction touch sensor on the right earbud two times quickly.
• Switch the noise level heard from the other party: Press the multifunction touch sensor on the right earbud two times quickly.
• Activate the voice assistant: Press and hold the multifunction touch sensor on the left earbud for about 2 seconds.

How to Activate The ANC Mode?

To activate or deactivate the ANC mode in these earbuds, all you have to do is to press and hold the multifunction touch sensor on the right earbud for about 2 seconds.

How to Activate The Ambient Mode?

To activate or deactivate the Ambient mode in these earbuds, all you have to do is to press and hold the multifunction touch sensor on the right earbud for about 2 seconds.

How to Activate The Mono Mode?

To activate or deactivate the mono mode in these earbuds, all you have to do is to pair the earbuds to the device and take out one of the earbuds from the charging case. It will start working by itself.

How to Charge The Earbuds?

Earbuds

To charge the earbuds, all you have to do is to place them into the charging case and close the lid. The earbuds will start charging automatically.

Charging case

To charge the charging case, all you have to do is to connect the case to a USB charger or charging port with the included USB-A to C cable. It will start charging automatically.

What Do The Lights Mean?

Earbuds

• A blue light flashes: The earbuds turn on.
• A blue and red light starts flashing: The earbuds are ready to pair with any device.
• A blue light flashes every 5 seconds: The earbuds are connected to the device.
• A blue light flashes two times when placed into the charging case: The earbuds started charging.
• A blue light flash for about 4 seconds while on the charging case: The earbuds are charging.
• The blue light turns off: The earbuds are fully charged.
• A blue light starts flashing quickly and turns off: The earbuds are resetting.

Charging case

• A red light on while charging: The case has a low battery.
• A yellow light on while charging: The case has a medium battery.
• A green light on while charging: The case has a high battery.
• The green light turns off while charging: The case is fully charged.

How to Reset The Earbuds?

Step 1: Delete all “EAH-AZ60” pairing information from the connected device.

Step 2: Place both earbuds into the charging case.

Step 3: Press and hold the multifunction touch sensor in one of the earbuds for about 7 seconds, until a blue and red light starts flashing.

Step 4: Release the finger from the touch sensor.

Step 5: Press and hold the multifunction touch sensor in said earbud for about 10 seconds, until a blue light starts flashing quickly and turns off. The resetting will be done for that earbud.

Step 6: Press and hold the multifunction touch sensor on the other earbud for about 7 seconds, until a blue and red light starts flashing.

Step 7: Release the finger from the touch sensor.

Step 8: Press and hold the multifunction touch sensor in said earbud for about 10 seconds, until a blue light starts flashing quickly and turns off. After that, the resetting will be done.

A Guide To Technics EAH-AZ60 APP

The Technics EAH-AZ60 earbuds have an application specially made for them, and it is the Technics Audio Connect app, which is available on Play Store and App Store. When entering the application, you have to connect to the earbuds.

• Home page: This is the first page of the app, where the connected earbuds appear, as well as the percentage of their battery. In addition to that, there are various options, such as configuring the Ambient Sound mode, finding the earbuds in case of loss, and a voice test.
• Ambient page: This is the specific section of Ambient mode, where it can be activated, modified and deactivated. Likewise, and if the earbud has the feature, the ANC can be configured.
• Sound page: Here, you can configure the sound profile that the earbuds will emit. It has three sound styles, although it can be configured according to what you want or need.
• Settings page: Here are the various options and functions of the earbuds. Not only can you change its name, but you can also add earbuds to the app, and configure some functions.

Some Common Problems & Troubleshooting

Left / Right / One side of the earbuds have stopped working

If this happens, it may be because it is low on battery or it did not connect correctly with the device. To fix this, you can do the following:

1. Try charging the earbud that is not working or both, placing them in the charging case.

2. Try factory resetting the earbuds.

3. Check if the earbuds are operating within a normal working range

If that doesn’t work, the earbud is probably faulty, and I can go for a refund or replacement of it.

Left / Right / One side of the earbuds has a low volume

If this happens, it may be because the earbuds are dirty or the volume is set low. To fix this, you can do the following:

1. Try cleaning the earbud using a cotton swab or carefully clean the mesh with a pin.

2. Try factory resetting the earbuds.

The microphone is not working

If this happens, it can be because the microphone is muted, or the earbuds are badly positioned. To fix this, you can do the following:

If the microphone is muted, check the device microphone volume. If that doesn’t work, that means that there might be a defect in the earbud, so try replacing them or get a refund.

The earbuds are not connecting to Windows/laptop/PC

If the earbuds are earbuds not connecting, it can be because the Bluetooth on the computer has a pairing problem. To fix this, you can do the following:

1. Try disabling Bluetooth from nearby devices >>> then activate the pairing mode of the earbuds, pair and connect earbuds from Settings >>> Bluetooth & other devices >>> Add a new device >>>> select Bluetooth.

2. Try uninstalling and reinstalling the Bluetooth driver, or updating the Bluetooth driver. All can be done in Manage >>> Device Manager, reset earbuds (if available), and then repeat the step.

3. Try resetting the earbuds.

FAQs

We hope you now know how to operate the earphone from the above Technics EAH-AZ60 manual. Want to know anything about the earphones? Do not hesitate to ask in the comments section.
