Kirin 820 Vs Snapdragon 765G Comparison – The King of Mid-End SoCs?

Last updated:

Recently, with the release of Huawei Honor 30S, Kirin 820 received a lot of attention due to its incredible performance. However, it has a similar tri-cluster configuration to the Snapdragon 765G. So, let’s test this SoC against the best upper mid-end SoCs in which Qualcomm has to provide which is (Snapdragon 765G) and see which one is the best upper-mid end SoC in this Kirin 820 Vs Snapdragon 765G comparison.

Kirin 820 Or Snapdragon 765G? The Battle For The Mid-End Supremacy!

Kirin 820 Vs Snapdragon 765G – Release Date Comparison

Kirin 820 was released on March 30. Honor 30S is the first and the only phone to date which features the Kirin 820 SoC.

Snapdragon 765 and 765G was released back in 2019 on December 6. The Redmi K30 5G was the first phone to feature it.

Kirin 820 Vs Snapdragon 765G – Process Comparison

Starting with the Kirin 820, we have the TSMC 7nm process which is also seen in the last year’s high-end Snapdragon 855 and 855+, but instead is N7P, DUV-based like the recent Snapdragon 865.

On the other hand, Snapdragon 765G is based on the latest 7nm LPP EUV process by Samsung. It’s the same process used in Kirin 990 and Exynos 990.

So, if we compare the process technology, which determines the performance/power efficiency, Snapdragon 765G has a much better process which allows it to have better energy utilization and heat dissipation than the Kirin 820. Why? Because of the EUV process allows 10 billion transistors (10.3 billion transistors) on a board area which is 36% less compared to the previous generation.

EUV vs Arf

However, remember that the EUV process allows more space on-board, however, the power efficiency gap between the second and third 7nm generations isn’t that much and one can’t even see this gap on the actual test.

Winner: Snapdragon 765G

Kirin 820 Vs Snapdragon 765G – CPU Comparison

Moving to the CPU section, Kirin 820 uses a tri-cluster layout on the octa-core design with the 1+3+4 core distribution. First, we have one high-performance Cortex-A76 core running at 2.36GHz. Then, we have the three mid-performance Cortex-A76 cores at 2.2GHz. Last but not least are the four power-efficient Cortex A55 cores running at a maximum frequency of 1.84 GHz.

Snapdragon 765G uses a Kyro 475 CPU based on a similar tri-cluster design (1+1+6) which is new in this 7 series. It consists of the one high-performance processor which is the new Kryo Prime CortexA76 running @2.4GHz, another Cortex-A76 but based on Kryo Gold running @2.2GHz and six energy-efficient CortexA55 cores running @1.8GHz. In comparison to SD 765, the G version has a slightly higher upper core frequency.

SoC Snapdragon 765G Kirin 820
High-Performance Cores 1 x Cortex A76 (2.4 GHz) 1 x Cortex A76 (2.36 GHz)
Mid-Performance Cores 1 x Cortex A76 (2.2GHz) 3 x Cortex A76 (2.2 GHz)
Low-Performance Cores 1 x Cortex A55 (1.8 GHz) 4 x Cortex A55 (1.84 GHz)
Process 7nm LPE EUV 7nm N7P FF+ TSMC

It’s good to see that both of them haven’t utilized the latest Cortex A77 core and saved for the next year’s 5nm process. Because Cortex A77 shows its full potential on the 5nm process.

Also Read: Kirin 985 vs Kirin 990 vs Kirin 990 5G vs Kirin 980 – HiSilicon’s Best SoC Is?

Anyways, comparing both CPUs, we see that the Kirin 820 has more mid-performance cores (3) compared to the Snapdragon 765G (1), which makes it stand out in multi-core performance. We have AnTuTu V8 Benchmarks to further prove the point. However, we should note that Snapdragon 765G is still the most energy-efficient SoC because of only one high and one mid-core.

Winner: Kirin 820

Kirin 820 Vs Snapdragon 765G – GPU Comparison

Kirin 820 features the new 6-core Mali-G57 MP6. The G57 is a mid-end GPU series with the new Valhall architecture. It has 30% better graphical performance, 30% better energy efficiency, and up to 60% performance improvement for ML workloads when compared to the previous generation which is Mali-G52. It is based on a 16 nm process and has a maximum frequency of 850 MHz.

Sd 765 gaming

SD 765G has upgraded its GPU from Adreno 618 to 620 which is also overclocked. The 765G’s overclocked Adreno 620 GPU has 35% better performance than the Adreno 618 in the 730. This is much better than the CPU improvement we just talked about in the above section. It’s based on the 7 nm process and has a frequency of 750 MHz.

SoC Snapdragon 765G Kirin 820
GPU Adreno 620 Mali-G57 MP6 (6 cores)
Speed 750MHz 850MHz

MediaTek Mali series GPUs have almost outperformed their level of Snapdragon Adreno GPUs, in the mid-end category. Comparing, the Mali-G57 MP6 with the Adreno 620, Mali is way ahead thanks to the 6 cores configuration and better frequency of each core. Even the 4-core Mali-G57 of Dimensity 800 beats the Adreno 620. The benchmark also proves this point.

Winner: Kirin 820

AnTuTu Scores Comparison

Here’s the comparison of Kirin 820 Vs Snapdragon 765 on AnTuTu Benchmark with other mid-end SoCs in the market:

Snapdragon 765G vs Kirin 820 AnTuTu

As you can see that the Kirin 820 scores around 375,270 points on AnTuTu v8 featured on Honor 30S. Meanwhile, Snapdragon 765G scores 322,826 points. Kirin 820 beats Snapdragon 765G in almost every section of the benchmark including CPU, GPU, and MEM, apart from the UX (slight difference).

Winner: Kirin 820

GeekBench Scores Comparison

From the rumors, in Geekbench 4, Kirin 820 achieves a score of 3490 in Single-Core and 11200 in Multi-Core performance. Surprisingly, the scores are tieing with the high-end processors of 2019, Kirin 980 and Snapdragon 855.

Kirin 820 GeekBench 4 Score Vs Snapdragon 855 Vs Kirin 980

Meanwhile, Snapdragon 765G (Redmi K30 5G) scores 3072 points in Single-Core and 7661 points in Multi-Core in Geekbench 4.

Kirin 820 vs Snapdragon 765G

Winner: Kirin 820

Kirin 820 Vs Snapdragon 765G – AI Comparison

In 2019, Kirin 810 topped the AI scoring chart and looks like Kirin 820 will again top the chart this 2020 for the mid-end because the Da-Vinci AI Engine has received a major improvement. Apart from the one big + two small cores, they have added another big core making it a Quad-core design. Due to this, the AI performance is a freaking 73% better over the AI of Kirin 810.

Snapdragon 765G incorporates the latest Hexagon 696 Processor for AI tasks and operations. In terms of AI performance, the SD 765G TOPs score is 5.3.

SoC Snapdragon 765G Kirin 820
NPU Hexagon 696 Da-Vinci (Dual NPU)
Score (Ai-Benchmark) 9108 points 41838 points

As listed by AI Benchmark, Kirin 820 Da-Vinci AI engine is in the top 4 with a score of 41838 points, beaten by Kirin 990 5G, Kirin 985, and MediaTek Dimensity 1000 SoCs. Meanwhile, Snapdragon 765G AI is not even near the top 10 list with a score of only 9108 points. The AI performance of Kirin 820 is almost 4.5X that of SD 765G.

Also Read: MediaTek Dimensity 800 vs Snapdragon 730G – MediaTek regaining the Mid-end SoC market

Kirin 985 vs Kirin 990 vs Kirin 990 5G vs Kirin 980 - Ai Benchmark Comparison

Winner: Kirin 820

Kirin 820 Vs Snapdragon 765G – Connectivity Comparison

The Kirin 820 features the same network modem as the Kirin 990 5G which is the Balong 5000 5G Modem. This modem supports both the SA-NSA 5G Mode and Multi-Mode 5G networks.

Snapdragon 765G supports 5G networking and is the first upper-mid SoC to provide this networking.  Snapdragon 765G integrating the X52 modem (internal) gives 5G download up to 3.7 Gbit/s and upload up to 1.6 Gbit/s. Moreover, it also supports Global 5G networking consisting of sub-6 GHz in Europe and Asia and mmWave 5G in the US. For 4G LTE, the download uses Cat 24 with a speed up to 1200 Mbit/s and for upload Cat 22 with a speed up to 210 Mbit/s.

SoC Snapdragon 765G Kirin 820
Modem Qualcomm X52 Balong 5000
Speed 5G mmWave: 3.7 Gbps (download) and upload up to 1.6 Gbps Sub-6GHz: 4.6 Gbps and 2.5 Gbps (download & upload)

mmWave: 6.5 Gbps and 3.5 Gbps

kirin-990-5g-vs-snapdragon-855-plus-vs-exynos-9825-vs-980-8

The Balong modem has a maximum download and upload speeds of 4.6 Gbps and 2.5 Gbps respectively in Sub 6GHz network. Whereas in the mmWave 5G network it can go up to 6.5 Gbps and 3.5 Gbps.

As we can see, that the 5G networking download and upload speed of Balong 5000 is way better than that of Qualcomm X52 modem. Meanwhile, the Snapdragon 765G’s download and upload speeds are 3.7 Gbps and 1.6 Gbps respectively for the mmWave 5G network.

Winner: Kirin 820

Kirin 820 Vs Snapdragon 765G – Price Comparison

The Kirin 820 will most likely be limited to Huawei flagships. The mid-end flagships from Huawei are much cheaper than Samsung, Vivo, OPPO, Sony and other famous manufacturers. Huawei Honor 30S will be the first phone to feature Kirin 820 with a starting price of $462.

The pricing of Snapdragon 765G may depend upon the manufacturer and the flagship. Since Qualcomm SoCs are not limited to a certain manufacturer, we might see a wide price range from starting from $280 to $450. The cheapest one and the first phone to use Snapdragon 765G is Xiaomi Redmi K30 5G which has the standard version selling for USD 284.

SoC Snapdragon 765G Kirin 820
First Phone Redmi K30 5G Honor 30S
Price $284 $462 (rumored)

Winner: Snapdragon 765G

Our Verdict

Kirin 820 is victorious in almost every aspect except for the price and process technology. Though SD 765G features a EUV process, however, compared to the 7nm N7P process the difference is in the size of the SoC and slightly in power efficiency. On a theoretical level, the difference can not be seen. Moreover, the price range also defines the selection of the SoC. Under $300 you can’t get a Kirin 820 for now but you can get a Snapdragon 765G. If Huawei launches a much cheaper smartphone with Kirin 820 from the Honor X or Magic series (under $350), then the price-performance ratio will be excellent.

Kirin 820 (6 Points) | Snapdragon 765G (2 Point)

Overall Winner: Kirin 820

Also Read: MediaTek Dimensity 800 vs Snapdragon 845 – 2020 vs 2017!

We hope you loved our Kirin 820 vs Snapdragon 765G comparison. Did we miss anything? Let us know in the comments.

Information is taken from (1), (2), (3)
